17
SPECIFICATIONS
Connections
Inputs
Connection Impedance Nominal Level Maximum Level
Phono RCA 47K/330pF 7mV-100mV
Line RCA 20K ohm -10 to +20dBu
FX RTN RCA 10K ohm 0 to +20dBu
Mic XLR <2K ohm -42 TO –12dBu
Outputs
Main Mix Balanced XLR 100 ohms +4dBu +28dBu
Monitor RCA 100 ohms -2dBu +22dBu
Record RCA 100 ohms -2dBu +19dBu
FX SND RCA 100 ohms -2dBu +19dBu
Headphones 3.5mm and
1/4” TRS Jacks
1 ohm 200mW RMS into
30 ohms
Performance
Distortion Main Mix out +10dBu 0.01% THD+N
Noise 22-22Khz Main Mix out unity -85dBu un-weighted
Fader shut off Channel fader >-80dB
Xfade shut off Xfader >-80dB
Frequency
Response
10Hz to 50kHz +/-0dB
Dimensions Weight 2.7kg (6lb)
Weight Packed
4kg (8.8lb)
