ALLEN&HEATH Xone:4D service manual AP7337_2 Page - 9 - of 14
PH,LN,SC
Round black
button
AJ4251
Up fader 003-860
Knob AJ5320
X- fader 003-579
Knob AJ5320
Pre black
button
AJ5388
FX, CH,
Pre button
AJ7286
FX1 & 2 AI8007
Knob AJ7304
Level AI8006
Knob AJ7304
HF, MF, LF AI8007
Knob AJ7305
