Allen & Heath 16 XONE:4D User Guide
TRAKTOR SET UP
Turn on your Xone:4D, launch your Traktor software and open the Preferences window.
1 In the Preferences window, expand the
Audio Setup section and select Soundcard. Set
the Audio Device to Xone:4D USB ASIO driv-
er
Now select Input Routing.
2 In the Input Routing section, assign the
Xone:4D analogue or digital inputs to the re-
quired deck.
Now select Output Routing.
3 In the Output Routing section, first make
sure that the Mixer Mode is set to External.
Now assign the Xone:4D analogue or digital out-
puts to the required deck.
4 In the Preferences window expand the
Hotkey & MIDI Setup section, select
MIDI Interfaces, double click the Active
box next the Xone:4D MIDI and an X will
appear. This will activate the MIDI from the
Xone:4D.
