ALLEN & HEATH Xone 4D User Manual

Allen & Heath 45 XONE:4D User Guide
CABLES AND CONNECTIONS
USB TYPE A USB TYPE B
MAX 2M
SPDIF RCA - 75 ohm coax
MIDI - 5-pin DIN
SPDIF OPTICAL - TOSLINK
1= ground
2= hot (+ )
3= cold (-)
BALANCED
XLR FEMALE
RCA phono jacks
XLR MALE
2= hot (+ )
1= ground
3= cold (-)
CABLE D
CABLE E
CABLE A
CABLE G
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
1= ground
2= hot (+ )
3= cold (-)
UNBALANCED
2= hot (+ )
1= ground
3= cold (-)
CABLE
F
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
CABLE H
BALANCED
BALANCED
XLR FEMALE
UNBALANCED
XLR FEMALE
XLR MALE
BALANCED
XLR MALE
UNBALANCED
UNBALANCED
CABLE
B
UNBALANCED
CABLE C
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
Sleeve= ground
Ring= cold (-)
Tip= hot (+ )
BALANCED
UNBALANCED
adapter
UNBALANCED
CABLE I
CABLE
J
CABLE K
CABLE L

ALLEN & HEATH Xone 4D Specifications

General

Sample rate	96 kHz
Frequency range	22 - 22000 Hz
Channels quantity	20 channels
Digital sound processing	24 bit
Microphone in	Yes
Product color	Black
Video capability	No
Equalizer bands quantity	3

Weight and Dimensions

Depth	358 mm
Width	432 mm
Height	88 mm
Weight	5000 g
Package depth	490 mm
Package width	575 mm
Package height	195 mm
Package weight	6000 g
