XONE:62 User Guide 5
Introduction
This user guide presents a quick reference to the XONE:62. We recommend that you read this
fully before starting. Included is information on installing, connecting and operating the console,
panel drawings, system block diagram and technical specification. For further information on the
basic principles of audio system engineering, please refer to one of the specialist publications
available from bookshops and audio equipment dealers.
Whilst we believe the information in this guide to be reliable we do not assume responsibility for
inaccuracies. We also reserve the right to make changes in the interest of further product
development.
Note that this user guide refers to the revised model XONE:62. This has minor changes from the
original model which it replaces. The order code for the revised model is XONE2:62/. The changes
include new styling with textured silver painted panel replacing the original stainless steel finish,
new knob style, a rotary rather than slider master level control, and new high grade Penny & Giles
crossfader instead of the original Alps version. The new crossfader is not interchangeable with the
older type.
We are able to offer further product support through our world-wide network of approved dealers
and service agents. You can also access our Web site on the Internet for information on our
product range, assistance with your technical queries or simply to chat about matters audio. To help
us provide the most efficient service please keep a record of your console serial number, and date
and place of purchase to be quoted in any communication regarding this product.
Check out our home site for information on the company and its pedigree, our full product range
and our design philosophy. We also have a site dedicated to the exciting XONE console range.
www.allen-heath.com
www.xone.co.uk
Contents
Warranty ................................................ 2
Important Safety Instructions ................ 3
Precautions ........................................... 4
Front and Rear Panel Drawings............ 6
Welcome to the XONE:62 ..................... 7
The Application ..................................... 8
Specifications ...................................... 10
Block Diagram..................................... 11
Input and Output Connections ........... 11
Quick Start........................................... 12
Gain and Operating Levels ................. 15
Connecting Mains Power.................... 16
Earthing................................................16
Plugging up the System ...................... 17
Cables and Connectors.......................18
Input Channels ....................................20
Crossfader and VCF ............................22
Replacing the Crossfader....................23
Filters Type Select ...............................24
Master Mix and Monitor System..........25
Glossary...............................................27
Tips and Troubleshooting ...................30
Cue Sheet ............................................31
Internet Site............................Rear Cover
