ALLEN & HEATH XONE 62 Service Manual

XONE:62 Service Manual 13
Power Supply
Internal switch mode power unit with auto sensing mains input.
MAINS IN socket IEC 3 pin
Power lead Country dependent with moulded mains plug supplied
AC mains 100 to 240V AC @ 50/60Hz
Consumption 30W max
Mains fuse rating 100-240V AC T500mA 20mm
Dimensions and Weights
The console is fitted with rubber feet for desktop operation. An optional screw on rack
ear kit is available for rack or plinth mounting.
Width Height Depth Weight
Desktop 320 mm (12.6”) 105 mm (4.1”) 358 mm (14.1”) 5 kg (11 lbs)
Rack ears fitted 370 mm (14.6”) 105 mm (4.1”) 358 mm (14.1”)
Packed 475 mm (18.7”) 210 mm (8.3”) 395 mm (15.6”) 5.5 kg (12 lbs)

ALLEN & HEATH XONE 62 Specifications

General

Channels quantity	6 channels
Digital sound processing	- bit
Number of EQ bands per channel	4
XLR out	2
Microphone in	Yes
Headphone connectivity	6.3 mm
Product color	Black
Video capability	No
