XONE:62 Service Manual 7
VERSION 1 and VERSION 2 Model Differences
There are minor changes between the original XONE:62 and the revised model
which replaced it in October 2000. This service manual covers both models.
Spares and support are available for both models. When servicing or ordering
spare parts for a XONE:62 first check which model it is.
The original model is referred to as VERSION 1. Its order code is XONE:62/.
Its key identifiers are:
Serial number sequence 020000
Stainless steel panel. Linear MIX master fader.
The newer model is referred to as VERSION 2. Its order code is XONE2:62/.
Its key identifiers are:
Serial number sequence 030000
Painted silver panel. Rotary MIX master control.
The following is a summary of the differences introduced on VERSION 2:
Styling The original stainless steel finish is replaced with a new textured silver
paint. Several knob and pushbutton types have been changed to further co-
ordinate the styling. There are minor changes to the graphics.
Master Level Controls The original MIX master linear fader has been
replaced with a rotary master control.
Crossfader The new high grade Penny & Giles fader is fitted instead of the
original Alps version. These are not interchangeable with VERSION 1.
Power Supply The power supply assembly was changed to improve
production efficiency.
The circuit information is mostly identical between the two models. Differences
are noted on the diagrams.
Order Codes
XONE:62 VERSION 1 not available
XONE:62 VERSION 2 XONE2:62/* (* = voltage)
Rack Ears for plinth mounting XONE2:62-RK
Rack Ears for 19” rack mounting XONE2:62-RK19
Crossfader Assembly VERSION 1 002-718 (Alps)
Crossfader Assembly VERSION 2 002-719 (P&G)
Stereo Fader Assembly 002-684
User Manual VERSION 1 AP3754
User Manual VERSION2 AP4145
Service Manual for both versions AP3842 (from issue 2)
