4 XONE:92 User Guide
Important Mains plug wiring instructions.
The console is supplied with a moulded mains plug fitted to the AC mains
power lead. Follow the instructions below if the mains plug has to be replaced.
The wires in the mains lead are coloured in accordance with the following
code:
WIRE COLOUR
TERMINAL
European USA/Canada
L
LIVE BROWN BLACK
N
NEUTRAL BLUE WHITE
E
EARTH GND GREEN & YELLOW GREEN
The wire which is coloured Green and Yellow must be connected to the
terminal in the plug which is marked with the letter E or with the Earth symbol.
This appliance must be earthed.
The wire which is coloured Blue must be connected to the terminal in the plug
which is marked with the letter N.
The wire which is coloured Brown must be connected to the terminal in the
plug which is marked with the letter L.
Ensure that these colour codes are followed carefully in the event of the plug
being changed.
Precautions
Damage : To prevent damage to the controls and cosmetics avoid placing heavy objects
on the control surface, scratching the surface with sharp objects, or rough
handling and vibration.
Environment : Protect from excessive dirt, dust, heat and vibration when operating and
storing. Avoid tobacco ash, smoke, drinks spillage, and exposure to rain and
moisture. If the console becomes wet, switch off and remove mains power
immediately. Allow to dry out thoroughly before using again.
Cleaning : Avoid the use of chemicals, abrasives or solvents. The control panel is best
cleaned with a soft brush and dry lint-free cloth. The faders, switches and
potentiometers are lubricated for life. The use of electrical lubricants on these
parts is not recommended.
Transporting : The console may be transported as a free-standing unit or mounted in a rack
or flightcase. Protect the controls from damage during transit. Use adequate
packing if you need to ship the unit.
Hearing : To avoid damage to your hearing do not operate any sound system at
excessively high volume. This also applies to any close-to-ear monitoring
such as headphones. Continued exposure to high volume sound can cause
frequency selective or wide range hearing loss. Make sure that your system
complies with any venue sound level and noise regulations which may apply.
!
