Assembly data
Production Line
Xone
Product
PX5
Assembly Stage
Final assembly
Issue Date
12/07/16
Revision Number
ISSUE 1
AH-M0773
24. FIT AA10220 SW. SLIDE CAP XONE: PX5 x2 AS SHOWN. FROM AA10182 KEYMAT
RUBBER XONE: PX5 CUT OUT AND FIT BUTTONS AS SHOWN. IMPORTANT: ENSURE ALL
BUTTONS ARE FITTED THE CORRECT WAY.
25. FIT AA10220 SW. SLIDE CAP XONE: PX5 x12 AS SHOWN.
26. FROM AA10182 KEYMAT RUBBER XONE: PX5 CUT OUT AND FIT LIGHTPIPE.
