16 POINT I/O Dual Port EtherNet/IP Adapter
Publication 1734-IN040C-EN-P - December 2018
Network
activity
Off No link established with Port 1 or Port 2.
Flashing green Transmit or receive activity present on Port 1 and/or Port 2 @ 100
Mb.
Transmit or receive activity present on Port 1 and/or Port 2.
One port @ 100 Mb and the other port @ 10 Mb.
Solid green Link established with Port 1 and/or Port 2 @ 100 Mb.
Link established with Port 1 and Port 2.
One port @ 100 Mb and the other port @ 10 Mb.
Solid yellow Link established with Port 1 and/or Port 2 @ 10 Mb.
Network
status
Off Device is not on-line
- Device has not completed dup_MAC_id test.
- Device not powered - check module status indicator
Flashing green Device is on-line but has no CIP connections in the established state.
Solid green Device on-line and has CIP connections in the established state.
Flashing red One or more CIP connections in timed-out state. Check for I/O
module failure and controller operation.
Note: This does not apply to POINTGuard I/O connection timeout.
Solid red Duplicate IP address detected.
Verify IP address setting and correct, as needed.
Flashing red/green Module self-test
POINTBus
status
Off Device is not online.
- Device has not completed Dup_MAC_ID test.
- Device not powered - check module status indicator.
Flashing green Device is online but has no connections in the established state.
Firmware (NVS) update in progress.
Solid green Adapter online with connections established.
Flashing red Recoverable fault occurred:
At cycle power, the number of expected modules does not equal the
number of modules present.
A module is missing.
Node fault (I/O connection timeout) occurred.
Solid red Unrecoverable fault occurred - thse adapter is bus off.
Flashing red/green LED powerup test is in progress.
System
power
Off Not active. Adapter power is off or there is a DC-DC converter
problem.
Solid green System power is on. DC-DC converter output is active (5V).
Field power Off Not active. Adapter power is off.
Solid green Power is on. 24V input is present.
Indicator Status for Modules
Indicator Status Description
