6 POINT I/O Dual Port EtherNet/IP Adapter
Publication 1734-IN040C-EN-P - December 2018
About The Adapter
Read this publication for information about the POINT I/O™ Dual Port EtherNet/IP™
adapter, a communications adapter for POINT I/O modules.
This adapter is for the POINT I/O backplane that provides connectivity to an
EtherNet/IP network with two RJ-45 connectors for 2 port pass-through to support
daisy-chain or ring, and the existing star and tree network topologies.
1734-AENTR Adapter
WARNING: Secure any external connections that mate to this equipment by
using screws, sliding latches, threaded connectors, or other means provided
with this product.
WARNING: Do not disconnect equipment unless power has been removed or
the area is known to be nonhazardous.
1734-AENTR
Module
Status
Network
Activity
Network
Status
Point Bus
Status
System
Power
Field
Power
POINT I O
02
0
2
Link 2
Activity/
Status
3
4
5
6
7
Link 1
Activity/
Status
