Page #8 background imageLoading...
Page #8 background image
8 POINT I/O Dual Port EtherNet/IP Adapter
Publication 1734-IN040C-EN-P - December 2018
Configure Autobaud
The adapter cannot reconfigure an I/O module that you previously configured to operate
at a fixed baud rate. When you reuse a POINT I/O module from another POINT I/O
system, configure the module to autobaud before using it with the adapter.
Install the Adapter
Follow this procedure to install the adapter on the DIN rail.
1. Position the adapter vertically above the DIN rail. Make sure that the DIN rail
lock is in horizontal position.
2. Press down firmly to install the adapter on a DIN rail, noting that the locking
mechanism locks the adapter to the DIN rail.
3. Set the node address on the node address pen push thumbwheel. See Set the
Network Address for more information on setting the IP address.
4. Slide the safety end cap up to remove it, exposing the backplane and power
interconnections.
ATTENTION: Do not discard the end cap. Use this end cap to cover the exposed
interconnections on the last mounting base on the DIN rail. Failure to do so
could result in equipment damage or injury from electric shock.
ATTENTION: This product is grounded through the DIN rail to chassis ground.
Use zinc plated chromate-passivated steel DIN rail to assure proper grounding.
The use of other DIN rail materials (for example, aluminum or plastic) that can
corrode, oxidize, or are poor conductors, can result in improper or intermittent
grounding. Secure DIN rail to mounting surface approximately every 200 mm
(7.8 in.) and use end-anchors appropriately. Be sure to ground the DIN rail
properly. Refer to Industrial Automation Wiring and Grounding Guidelines,
Rockwell Automation publication 1770-4.1
, for more information.
ATTENTION: Allow 25.4 mm (1 in.) of space between adjacent equipment for
adequate ventilation.
