Rockwell Automation Publication 1769-IN015D-EN-P - October 2017 7
Compact I/O End Caps/Terminators
1769-ECR and 1769-ECRK Dimensions
32 mm
(1.26 in.)
18 mm
(0.71 in.)
118 mm
(4.65 in.)
85 mm
(3.35 in.)
