Allen-Bradley 1769-ECR User Manual

8 Rockwell Automation Publication 1769-IN015D-EN-P - October 2017
Compact I/O End Caps/Terminators
Specifications
Environmental Specifications
Attribute 1769-ECL 1769-ECR, 1769-ECRK
Current draw at 5.1V DC 5 mA
Current draw at 24V DC 0 mA
Operating altitude 2000 m (6562 ft)
North American temp code T3C
IEC temp code — T4
Shipping weight, approx 130 g (0.286 lb)
Enclosure type rating None (open style)
Attribute 1769-ECL 1769-ECR, 1769-ECRK
Operating temperature
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 > Ta > 60 °C (32 > Ta > 140 °F)
Nonoperating temperature
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating
Cold)
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating
Dry Heat)
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating
Thermal Shock)
-40 > Ta > 85 °C (-40 > Ta > 185 °F)
Relative humidity 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating)
5 g, 10…500 Hz
Operating shock
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
DIN rail mount: 20 g; Panel mount: 30 g
Nonoperating shock
IEC 60068-2-27 (Test Ea, Unpackaged Shock)
DIN rail mount: 30 g; Panel mount: 40 g
Emissions
CISPR 11
Group 1, Class A
ESD immunity
IEC 61000-4-2
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3
10V/m with 1 kHz sine-wave 80% AM from 80…2700 MHz
10V/m with 200 Hz 50%Pulse 100% AM at 900 MHz
10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
