Allen-Bradley 1769-L30ER Quick Start

Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012 29
Prepare the CompactLogix 5370 L3 Controller Hardware Chapter 1
Make a DeviceNet Network Connection (Optional)
1. Attach and lock the
1606-XLDNET8 DeviceNet
power supply to the DIN rail.
The power supply uses a locking
tab at the top that you push down
to secure it to the DIN rail.
2. Assemble the DeviceNet network
cable system using the KwikLink
flat cable, terminators, and sealed
micro connectors for each device.
See instructions included
with devices.
3. Wire a KwikLink QD Micro
Cordset to the 1769-SDN
connector.
Connect To
Red V+
White CAN High
Bare Shield
Blue CAN Low
Black V-
Input
AC 100-120/200-240V
N L
Isolate power before disconnecting
1606-XL
POWER SUPPLY
DC ok
Output
200W Limited Power
DC 24V / 8A
+ –
DC ok
AC 120V
AC 240V
Input
AC 100-120/200-240V
N L
Iso
la
t
e
p
o
w
e
r b
e
fo
r
e
dis
c
o
n
n
e
ctin
g
1606-XL
POWER SUPPLY
DC
ok
Output
200W Limi
ted Power
DC 2
4V / 8A
+ –
DC ok
AC
120V
AC
240V
To other device on
network
To other device on
network
1606-XLDNET8
DeviceNet Power Supply
KwikLink Sealed
Termi nator
KwikLink Sealed
Termi nator
KwikLink Sealed
Micro Connector
