Allen-Bradley 1769-L30ER Quick Start

Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012 65
Create a Logix Designer Project Chapter 5
Follow These Steps
Create a Project
Configure the Controller
Add Local I/O Module
Add Ladder Logic to Test
the Local 1769-OB16
Module
Download to the
Controller and Test the
Logic
Add the 1769-SDN to
the Project
page 66
page 68
page 70
page 73
page 76
page 71

Allen-Bradley 1769-L30ER Specifications

General

Brand	Allen-Bradley
Model	1769-L30ER
Category	Controller
Language	English
