186 Rockwell Automation Publication 1769-UM021G-EN-P - October 2015
Chapter 8 Use I/O Modules with CompactLogix 5370 L2 Controllers
Figure 26 shows an example wiring diagram for the embedded digital
input points.
Figure 26 - CompactLogix 5370 L2 Controllers Embedded Digital Input Point Wiring Diagram
Figure 27 shows an example wiring diagram for the embedded digital
output points.
Figure 27 - CompactLogix 5370 L2 Controllers Embedded Digital Output Point Wiring Diagram
+ DC (Sinking)
- DC (Sourcing)
- DC (Sinking)
+ DC (Sourcing)
24V DC
+ DC
24V DC
- DC
