Input Power Wiring Requirements
Drive Cat. No. Input Type Signals Terminals
Wire Size
mm
2
(AWG)
Torque Value
N•m (lb•in)
2099-BM06
2099-BM07
2099-BM08
AC input
L1
L2
L3
Ground
R
S
T
PE
25…2.5
(3…14)
1.8 (16)
Motor power
U/Brown
V/Black
W/Blue
Green/Yellow
U
V
W
DC bus DC+, DC- DC+, DC-
2099-BM09
AC input
L1
L2
L3
R
S
T
50…4
(1/0…12)
3.6 (32)
Ground PE 5.0 (44)
Motor power
U/Brown
V/Black
W/Blue
U
V
W
3.6 (32)
Green/Yellow
5.0 (44)
DC bus DC+, DC- DC+, DC- 3.6 (32)
2099-BM10
AC input
L1
L2
L3
R
S
T
70…10
(2/0…8)
15 (133)
Ground PE
50…4
(1/0…12)
5.0 (44)
Motor power
U/Brown
V/Black
W/Blue
U
V
W
70…10
(2/0…8)
15 (133)
Green/Yellow
50…4
(1/0…12)
5.0 (44)
DC bus DC+, DC- DC+, DC-
70…10
(2/0…8)
15 (133)
2099-BM11
2099-BM12
AC input
L1
L2
L3
R
S
T
100…10
(4/0…8)
12 (104)
Ground PE
50…4
(1/0…12)
5.0 (44)
Motor power
U/Brown
V/Black
W/Blue
U
V
W
100…10
(4/0…8)
12 (104)
Green/Yellow
50…4
(1/0…12)
5.0 (44
)
DC bus D
C+, DC- DC+, DC-
100…10
(4/0…8)
12 (104)
