Allen-Bradley 20A User Manual

Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017 39
Selecting An External Resistor for PowerFlex 7-Class Drives Chapter 4
154.00 Ohms
154.00 182 6416 222-1A PG/IPC
154.00 242 6416 222-1 PG/IPC
154.00 400 7800 PR2205-1 PowerOhm
154.00 408 6416 225-1A PG/IPC
154.00 604 16431 225-1 PG/IPC
154.00 610 16431 220-1A PG/IPC
154.00 800 12300 PR225-1 PowerOhm
154.00 913 16431 220-1 PG/IPC
150.00 Ohms
150.00 400 7700 PF150R400W PowerOhm
150.00 800 12100 PF150R800W PowerOhm
150.00 1200 30000 PF150R1K20 PowerOhm
150.00 1600 54200 PF150R1K60 PowerOhm
150.00 2000 53500 PF150R2K00 PowerOhm
150.00 2400 82500 PF150R2K40 PowerOhm
150.00 2800 132000 PF150R2K80 PowerOhm
150.00 3200 136500 PF150R3K20 PowerOhm
150.00 3600 196200 PF150R3K60 PowerOhm
150.00 4000 192400 PF150R4K00 PowerOhm
150.00 5200 333400 PF150R5K20 PowerOhm
150.00 5600 329100 PF150R5K60 PowerOhm
128.00 Ohms
128.00 400 6500 PR4405-6 PowerOhm
128.00 800 18500 PR4410-6 PowerOhm
128.00 874 22065 442-6A PG/IPC
128.00 1162 32863 442-6 PG/IPC
128.00 1200 25500 PR442-6 PowerOhm
128.00 1600 45500 PR445-6A PowerOhm
128.00 1951 55397 445-6A PG/IPC
128.00 2400 114800 PR445-6 PowerOhm
128.00 2906 86382 445-6 PG/IPC
128.00 2912 82626 440-6A PG/IPC
128.00 3600 164100 PR440-6 PowerOhm
128.00 4395 138024 440-6 PG/IPC
125.00 Ohms
125.00 400 6500 PF125R400W PowerOhm
125.00 800 18000 PR5505-7 PowerOhm
125.00 800 18300 PF125R800W PowerOhm
125.00 1200 24900 PR5510-7 PowerOhm
125.00 1200 25200 PF125R1K20 PowerOhm
125.00 1386 32863 552-7A PG/IPC
125.00 1600 44200 PF125R1K60 PowerOhm
125.00 1850 51954 552-7 PG/IPC
125.00 2000 68700 PF125R2K00 PowerOhm
125.00 2800 112100 PR555-7A PowerOhm
125.00 3095 130903 555-7A PG/IPC
125.00 3600 161600 PF125R3K60 PowerOhm
125.00 4000 267000 PR555-7 PowerOhm
125.00 4000 277800 PF125R4K00 PowerOhm
125.00 4620 208131 550-7A PG/IPC
125.00 4625 208131 555-7 PG/IPC
125.00 5600 282800 PR550-7 PowerOhm
125.00 6994 212513 550-7 PG/IPC
125.00 7200 341300 PF125R7K20 PowerOhm
125.00 7600 344600 PF125R7K60 PowerOhm
120.00 Ohms
120.00 260 52000 AKR2120P1K2 Rockwell
Ohms Watts Watt Seconds Catalog Manufacturer
