40 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
117.00 Ohms
117.00 150 1200 PR117R150W PowerOhm
117.00 250 6000 PR117R250W PowerOhm
117.00 300 6000 PRT117R300W PowerOhm
117.00 300 7950 T117R300W PG/IPC
117.00 400 6000 PR117R400W PowerOhm
117.00 600 10100 T117R600W PG/IPC
117.00 600 17000 PRT117R600W PowerOhm
117.00 800 17000 PR117R800W PowerOhm
117.00 900 10600 T117R900W PG/IPC
117.00 900 23400 PRT117R900W PowerOhm
117.00 1200 12500 T117R1K2 PG/IPC
117.00 1200 41700 PR117R1K20 PowerOhm
117.00 1500 15800 T117R1K5 PG/IPC
117.00 1500 66700 PRT117R1K5 PowerOhm
117.00 1600 66700 PR117R1K60 PowerOhm
117.00 1800 66700 PR117R1K80 PowerOhm
117.00 2100 18600 T117R2K1 PG/IPC
117.00 2100 150000 PRT117R2K1 PowerOhm
117.00 2250 105000 PR117R2K25 PowerOhm
117.00 2700 14300 T117R2K7 PG/IPC
117.00 2700 150000 PRT117R2K7 PowerOhm
117.00 3000 20800 T117R3K0 PG/IPC
117.00 3000 250000 PRT117R3K0 PowerOhm
110.00 Ohms
110.00 255 7511 222-2A PG/IPC
110.00 338 7511 222-2 PG/IPC
110.00 400 5600 PR2205-2 PowerOhm
110.00 570 18779 225-2A PG/IPC
110.00 800 15900 PR225-2 PowerOhm
110.00 845 18779 225-2 PG/IPC
110.00 850 18779 220-2A PG/IPC
110.00 1200 39100 PR220-2 PowerOhm
110.00 1278 46947 220-2 PG/IPC
100.00 Ohms
100.00 400 5200 PF100R400W PowerOhm
100.00 800 20000 PF100R800W PowerOhm
100.00 1200 35300 PF100R1K20 PowerOhm
100.00 1600 55000 PF100R1K60 PowerOhm
100.00 2000 89800 PF100R2K00 PowerOhm
100.00 2400 130800 PF100R2K40 PowerOhm
100.00 2800 125700 PF100R2K80 PowerOhm
100.00 3600 211600 PF100R3K60 PowerOhm
100.00 4000 205200 PF100R4K00 PowerOhm
100.00 4800 285500 PF100R4K80 PowerOhm
100.00 5200 275000 PF100R5K20 PowerOhm
100.00 5600 273100 PF100R5K60 PowerOhm
100.00 6800 450100 PF100R6K80 PowerOhm
100.00 8000 692400 PF100R8K00 PowerOhm
100.00 9200 676300 PF100R9K20 PowerOhm
97.00 Ohms
97.00 150 2200 PR97R150W PowerOhm
97.00 250 5000 PR97R250W PowerOhm
97.00 300 5000 PRT97R300W PowerOhm
97.00 300 10300 T97R300W PG/IPC
97.00 400 5000 PR97R400W PowerOhm
97.00 600 13400 T97R600W PG/IPC
97.00 600 19400 PRT97R600W PowerOhm
97.00 800 19400 PR97R800W PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
