Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017 41
Selecting An External Resistor for PowerFlex 7-Class Drives Chapter 4
97.00 900 13800 T97R900W PG/IPC
97.00 900 34600 PRT97R900W PowerOhm
97.00 1200 16500 T97R1K2 PG/IPC
97.00 1200 34600 PR97R1K20 PowerOhm
97.00 1200 55300 PRT97R1K2 PowerOhm
97.00 1500 20800 T97R1K5 PG/IPC
97.00 1500 87100 PRT97R1K5 PowerOhm
97.00 1600 55300 PR97R1K60 PowerOhm
97.00 2100 15400 T97R2K1 PG/IPC
97.00 2100 124400 PRT97R2K1 PowerOhm
97.00 2250 87100 PR97R2K25 PowerOhm
97.00 2700 19100 T97R2K7 PG/IPC
97.00 2700 124400 PR97R2K70 PowerOhm
97.00 2700 207300 PRT97R2K7 PowerOhm
97.00 3000 16800 T97R3K0 PG/IPC
97.00 3000 199000 PRT97R3K0 PowerOhm
97.00 3600 22400 T97R3K6 PG/IPC
97.00 3600 207200 PR97R3K60 PowerOhm
97.00 3600 278000 PRT97R3K6 PowerOhm
97.00 4200 19100 T97R4K2 PG/IPC
97.00 4200 266500 PRT97R4K2 PowerOhm
91.00 Ohms
91.00 86 17000 AKR2091P500 Rockwell
85.00 Ohms
85.00 326 9076 222-3A PG/IPC
85.00 400 6800 PR2205-3 PowerOhm
85.00 400 6900 PF85R400W PowerOhm
85.00 438 9076 222-3 PG/IPC
85.00 730 23004 225-3A PG/IPC
85.00 800 16900 PR225-3A PowerOhm
85.00 800 17200 PF85R800W PowerOhm
85.00 1089 36384 220-3A PG/IPC
85.00 1094 36384 225-3 PG/IPC
85.00 1200 46200 PF85R1K20 PowerOhm
85.00 1200 48400 PR225-3 PowerOhm
85.00 1600 75400 PF85R1K60 PowerOhm
85.00 1600 76200 PR220-3 PowerOhm
85.00 1654 57901 220-3 PG/IPC
85.00 2000 109000 PF85R2K00 PowerOhm
85.00 2056 57588 552-8A PG/IPC
85.00 2400 108900 PR552-8 PowerOhm
85.00 2720 92016 552-8 PG/IPC
85.00 2800 179500 PF85R2K80 PowerOhm
85.00 3600 173600 PF85R3K60 PowerOhm
85.00 3600 174300 PR555-8A PowerOhm
85.00 4592 233795 555-8A PG/IPC
85.00 5200 379200 PF85R5K20 PowerOhm
85.00 5600 381400 PR555-8 PowerOhm
85.00 5600 383300 PF85R5K60 PowerOhm
85.00 6800 588500 PF85R6K80 PowerOhm
85.00 6801 231135 555-8 PG/IPC
85.00 6854 231135 550-8A PG/IPC
85.00 7200 578500 PF85R7K20 PowerOhm
85.00 8800 953500 PR550-8 PowerOhm
85.00 10000 934100 PF85R10K0 PowerOhm
85.00 10285 361490 550-8 PG/IPC
85.00 11200 923100 PF85R11K2 PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
