Allen-Bradley 20A User Manual

Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017 43
Selecting An External Resistor for PowerFlex 7-Class Drives Chapter 4
80.00 9000 1435900 PRT80R9K0 PowerOhm
80.00 9300 230000 T80R9K3 PG/IPC
80.00 9300 1435900 PRT80R9K3 PowerOhm
77.00 Ohms
77.00 250 6200 PR77R250W PowerOhm
77.00 300 6200 PRT77R300W PowerOhm
77.00 300 8210 T77R300W PG/IPC
77.00 400 6200 PR77R400W PowerOhm
77.00 600 10600 T77R600W PG/IPC
77.00 600 15400 PRT77R600W PowerOhm
77.00 800 27500 PR77R800W PowerOhm
77.00 900 17900 T77R900W PG/IPC
77.00 900 43900 PRT77R900W PowerOhm
77.00 1200 20800 T77R1K2 PG/IPC
77.00 1200 43900 PR77R1K20 PowerOhm
77.00 1200 69200 PRT77R1K2 PowerOhm
77.00 1500 16400 T77R1K5 PG/IPC
77.00 1500 98800 PRT77R1K5 PowerOhm
77.00 1600 69100 PR77R1K60 PowerOhm
77.00 1800 69100 PR77R1K80 PowerOhm
77.00 2100 19100 T77R2K1 PG/IPC
77.00 2100 164600 PRT77R2K1 PowerOhm
77.00 2250 98800 PR77R2K25 PowerOhm
77.00 2700 23800 T77R2K7 PG/IPC
77.00 2700 220700 PRT77R2K7 PowerOhm
77.00 3000 21300 T77R3K0 PG/IPC
77.00 3000 211600 PRT77R3K0 PowerOhm
77.00 3150 158000 PR77R3K15 PowerOhm
77.00 3600 28100 T77R3K6 PG/IPC
77.00 3600 157900 PR77R3K60 PowerOhm
77.00 3600 211600 PRT77R3K6 PowerOhm
77.00 4050 220600 PR77R4K05 PowerOhm
77.00 4200 24200 T77R4K2 PG/IPC
77.00 4200 341100 PRT77R4K2 PowerOhm
77.00 4500 22400 T77R4K5 PG/IPC
77.00 4500 533100 PRT77R4K5 PowerOhm
77.00 5700 28700 T77R5K7 PG/IPC
77.00 5700 863800 PRT77R5K7 PowerOhm
77.00 9000 209000 T77R9K0 PG/IPC
77.00 9000 1382100 PRT77R9K0 PowerOhm
77.00 9300 230000 T77R9K3 PG/IPC
77.00 9300 1382100 PRT77R9K3 PowerOhm
70.00 Ohms
70.00 400 5700 PF70R400W PowerOhm
70.00 800 24900 PR5505-9A PowerOhm
70.00 800 25000 PF70R800W PowerOhm
70.00 1200 39800 PR5505-9 PowerOhm
70.00 1200 62000 PF70R1K20 PowerOhm
70.00 2000 89700 PR5510-9 PowerOhm
70.00 2400 153900 PF70R2K40 PowerOhm
70.00 2527 76680 552-9A PG/IPC
70.00 2800 143500 PR552-9 PowerOhm
70.00 3303 144048 552-9 PG/IPC
70.00 4800 114200 PR555-9A PowerOhm
70.00 4800 308300 PF70R4K80 PowerOhm
70.00 5643 189665 555-9A PG/IPC
70.00 7200 785200 PR555-9 PowerOhm
70.00 8258 297173 555-9 PG/IPC
70.00 8424 295765 550-9A PG/IPC
Ohms Watts Watt Seconds Catalog Manufacturer
