44 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
70.00 9600 1249300 PF70R9K60 PowerOhm
70.00 10400 251200 PR550-9 PowerOhm
70.00 12489 482144 550-9 PG/IPC
65.00 Ohms
65.00 400 9500 PF65R400W PowerOhm
65.00 800 23600 PF65R800W PowerOhm
65.00 1200 59300 PF65R1K20 PowerOhm
65.00 2000 138900 PF65R2K00 PowerOhm
65.00 2400 141100 PF65R2K40 PowerOhm
65.00 3600 178100 PF65R3K60 PowerOhm
65.00 4000 291700 PF65R4K00 PowerOhm
65.00 7200 712100 PF65R7K20 PowerOhm
65.00 7600 709900 PF65R7K60 PowerOhm
65.00 16640 690800 PF65R16K6 PowerOhm
60.00 Ohms
60.00 150 3400 PR60R150W PowerOhm
60.00 250 8700 PR60R250W PowerOhm
60.00 300 8700 PRT60R300W PowerOhm
60.00 300 10300 T60R300W PG/IPC
60.00 400 8700 PF60R400W PowerOhm
60.00 520 104000 2-AKR2120P1K2 Rockwell
60.00 600 13000 T60R600W PG/IPC
60.00 600 21400 PRT60R600W PowerOhm
60.00 800 21400 PF60R800W PowerOhm
60.00 800 34200 PR60R800W PowerOhm
60.00 900 13700 T60R900W PG/IPC
60.00 900 53900 PRT60R900W PowerOhm
60.00 1200 16400 T60R1K2 PG/IPC
60.00 1200 53900 PR60R1K20 PowerOhm
60.00 1200 77000 PRT60R1K2 PowerOhm
60.00 1500 20800 T60R1K5 PG/IPC
60.00 1500 128300 PRT60R1K5 PowerOhm
60.00 2000 128300 PF60R2K00 PowerOhm
60.00 2250 128300 PR60R2K25 PowerOhm
60.00 2700 18500 T60R2K7 PG/IPC
60.00 2700 123100 PR60R2K70 PowerOhm
60.00 2700 164900 PRT60R2K7 PowerOhm
60.00 3600 22000 T60R3K6 PG/IPC
60.00 3600 164900 PR60R3K60 PowerOhm
60.00 3600 415400 PRT60R3K6 PowerOhm
60.00 4000 269300 PF60R4K00 PowerOhm
60.00 4500 28000 T60R4K5 PG/IPC
60.00 4500 269300 PR60R4K50 PowerOhm
60.00 4500 673100 PRT60R4K5 PowerOhm
60.00 4950 265600 PR60R4K95 PowerOhm
60.00 5850 409800 PR60R5K85 PowerOhm
60.00 6900 164000 T60R6K9 PG/IPC
60.00 6900 1077000 PRT60R6K9 PowerOhm
60.00 7650 657600 PR60R7K65 PowerOhm
60.00 8000 659400 PF60R8K00 PowerOhm
60.00 11000 448000 T60R11K0 PG/IPC
60.00 11000 2051300 PRT60R11K0 PowerOhm
60.00 15896 690800 PF60R15K8 PowerOhm
59.00 Ohms
59.00 400 8500 PR2205-4 PowerOhm
59.00 473 10094 222-4A PG/IPC
59.00 631 25038 222-4 PG/IPC
59.00 800 33600 PR222-4 PowerOhm
59.00 1056 39201 225-4A PG/IPC
Ohms Watts Watt Seconds Catalog Manufacturer
