58 Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017
Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
13.00 2800 238800 PF13R2K80 PowerOhm
13.00 3328 144900 PR13R3K32 PowerOhm
13.00 5200 193100 PR13R5K20 PowerOhm
13.00 5457 191600 PF13R5K45 PowerOhm
13.00 11000 1048200 PF13R11K0 PowerOhm
12.00 Ohms
12.00 400 82100 PR12R400W PowerOhm
12.00 800 131900 PR12R800W PowerOhm
12.00 1200 134700 PR12R1K20 PowerOhm
12.00 2250 215400 PR12R2K25 PowerOhm
12.00 2400 215300 PR4405-14A PowerOhm
12.00 3072 133600 PR12R3K07 PowerOhm
12.00 3888 140800 PR5505-16A PowerOhm
12.00 3888 155500 PR4405-14 PowerOhm
12.00 4800 191500 PR4410-14A PowerOhm
12.00 6348 342000 PR12R6K34 PowerOhm
12.00 6348 376000 PR5505-16 PowerOhm
12.00 8112 500400 PR4410-14 PowerOhm
12.00 9641 440372 442-14A PG/IPC
12.00 10092 898400 PR442-14A PowerOhm
12.00 10092 1048100 PR5510-16 PowerOhm
12.00 12288 1433800 PR552-16A PowerOhm
12.00 12398 890985 442-14 PG/IPC
12.00 13780 890985 552-16A PG/IPC
12.00 15552 1955200 PR442-14 PowerOhm
12.00 19200 3595700 PR552-16 PowerOhm
12.00 20673 599876 552-16 PG/IPC
12.00 21531 1924486 445-14A PG/IPC
12.00 24300 3941400 PR445-14A PowerOhm
12.00 30000 6169500 PR445-14 PowerOhm
12.00 30000 6450000 PR555-16A PowerOhm
12.00 30776 1040221 555-16A PG/IPC
12.00 32136 1040221 440-14A PG/IPC
12.00 32297 1040221 445-14 PG/IPC
12.00 43200 10984300 PR555-16 PowerOhm
12.00 45934 2387466 550-16A PG/IPC
12.00 46170 2247026 555-16 PG/IPC
12.00 48204 1314510 440-14 PG/IPC
12.00 58800 16476500 PR440-14 PowerOhm
12.00 68911 10015318 550-16 PG/IPC
12.00 86700 28607000 PR550-16 PowerOhm
11.00 Ohms
11.00 800 17900 PR2205-9A PowerOhm
11.00 1200 48300 PR2205-9 PowerOhm
11.00 1600 39400 PR2210-9A PowerOhm
11.00 2000 197400 PR2210-9 PowerOhm
11.00 2400 197400 PR222-9A PowerOhm
11.00 2561 121123 222-9A PG/IPC
11.00 3381 100080 222-9 PG/IPC
11.00 3564 116600 PR222-9 PowerOhm
11.00 5720 237243 225-9A PG/IPC
11.00 5819 321000 PR225-9A PowerOhm
11.00 8454 407344 225-9 PG/IPC
11.00 8537 407344 220-9A PG/IPC
11.00 9251 898400 PR225-9 PowerOhm
11.00 12784 890985 220-9 PG/IPC
11.00 14256 1737900 PR220-9 PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
