Allen-Bradley 20A User Manual

Rockwell Automation Publication PFLEX-AT001L-EN-P - September 2017 59
Selecting An External Resistor for PowerFlex 7-Class Drives Chapter 4
10.40 Ohms
10.40 300 17300 T10F4R300W PG/IPC
10.40 300 21400 PRT10F4R300W PowerOhm
10.40 600 22900 T10F4R600W PG/IPC
10.40 600 46100 PRT10F4R600W PowerOhm
10.40 900 24500 T10F4R900W PG/IPC
10.40 900 114300 PRT10F4R900W PowerOhm
10.40 1500 25400 T10F4R1K5 PG/IPC
10.40 1500 186700 PRT10F4R1K5 PowerOhm
10.40 1800 186700 PR10F4R1K80 PowerOhm
10.40 2662 115900 PR10F4R2K66 PowerOhm
10.40 2970 81600 PRT10F4R2K97 PowerOhm
10.40 2970 95100 T10F4R2K97 PG/IPC
10.40 4160 153300 PR10F4R4K16 PowerOhm
10.40 5360 274400 PRT10F4R5K36 PowerOhm
10.40 5360 329000 T10F4R5K36 PG/IPC
10.40 6040 274400 PRT10F4R6K4 PowerOhm
10.40 6040 489000 T10F4R6K4 PG/IPC
10.40 8746 855700 PR10F4R8K74 PowerOhm
10.40 8890 770300 PRT10F4R8K89 PowerOhm
10.40 8890 801000 T10F4R8K89 PG/IPC
10.40 11000 359000 T10F4R11K0 PG/IPC
10.40 11000 1168200 PRT10F4R11K0 PowerOhm
10.40 15500 1742000 T10F4R15K5 PG/IPC
10.40 15500 2490600 PRT10F4R15K5 PowerOhm
10.40 16640 2966900 PR10F4R16K6 PowerOhm
10.40 18900 1991000 T10F4R18K9 PG/IPC
10.40 18900 3790000 PRT10F4R18K9 PowerOhm
10.40 26000 2002000 T10F4R26K0 PG/IPC
10.40 26000 5718700 PR10F4R26K0 PowerOhm
10.40 26000 5885300 PRT10F4R26K0 PowerOhm
10.40 35600 1230000 T10F4R35K6 PG/IPC
10.40 35600 10024700 PRT10F4R35K6 PowerOhm
10.40 43900 1367000 T10F4R43K9 PG/IPC
10.40 43900 14328100 PRT10F4R43K9 PowerOhm
10.40 72300 4620000 T10F4R72K3 PG/IPC
10.40 72300 18257600 PRT10F4R72K3 PowerOhm
10.10 Ohms
10.10 400 20600 PF10F1R400W PowerOhm
10.10 800 35900 PF10F1R800W PowerOhm
10.10 1200 112100 PF10F1R1K20 PowerOhm
10.00 4000 163500 PR5505-17A PowerOhm
10.00 6760 400300 PR5505-17 PowerOhm
10.00 8410 898400 PR5510-17A PowerOhm
10.00 12960 1737900 PR5510-17 PowerOhm
10.00 16000 2824200 PR552-17A PowerOhm
10.00 17713 479901 552-17A PG/IPC
10.00 25000 5328200 PR552-17 PowerOhm
10.00 26569 903350 552-17 PG/IPC
10.00 36000 8787400 PR555-17A PowerOhm
10.00 39559 1956117 555-17A PG/IPC
10.00 49000 13730400 PR550-17A PowerOhm
10.00 51840 6453800 PR555-17 PowerOhm
10.00 59043 1950414 550-17A PG/IPC
10.00 59339 1950414 555-17 PG/IPC
9.50 Ohms
9.50 3800 135500 PR4405-15A PowerOhm
9.50 5025 266000 PR4405-15 PowerOhm
9.50 6422 400300 PR4410-15A PowerOhm
Ohms Watts Watt Seconds Catalog Manufacturer
