Chapter 4 Selecting An External Resistor for PowerFlex 7-Class Drives
9.50 9728 1075300 PR4410-15 PowerOhm
9.50 11926 316618 442-15A PG/IPC
9.50 12312 1520700 PR442-15A PowerOhm
9.50 15200 2596900 PR442-15 PowerOhm
9.50 17890 479901 442-15 PG/IPC
9.50 23750 5047800 PR445-15A PowerOhm
9.50 26636 3000513 445-15A PG/IPC
9.50 34200 8787400 PR445-15 PowerOhm
9.50 38912 4056700 PR440-15A PowerOhm
9.50 39755 2851152 440-15A PG/IPC
9.50 39955 1079776 445-15 PG/IPC
9.50 49248 6146500 PR440-15 PowerOhm
9.50 59635 1820386 440-15 PG/IPC
9.20 Ohms
9.20 400 18900 PF9F2R400W PowerOhm
9.20 800 32400 PF9F2R800W PowerOhm
9.20 1200 102200 PF9F2R1K20 PowerOhm
9.20 1600 75500 PF9F2R1K60 PowerOhm
9.20 2000 161600 PF9F2R2K00 PowerOhm
9.20 2355 98000 PF9F2R2K35 PowerOhm
9.20 2981 116700 PF9F2R2K98 PowerOhm
9.20 3751 135600 PF9F2R3K75 PowerOhm
9.20 4867 282100 PF9F2R4K86 PowerOhm
9.20 6601 341800 PF9F2R6K60 PowerOhm
9.20 7737 748700 PF9F2R7K73 PowerOhm
9.20 9421 1075400 PF9F2R9K42 PowerOhm
9.20 11923 1520800 PF9F2R11K9 PowerOhm
9.20 15001 545200 PF9F2R15K0 PowerOhm
9.20 19467 1064100 PF9F2R19K4 PowerOhm
9.20 24876 1416000 PF9F2R24K8 PowerOhm
9.20 30948 2965500 PF9F2R30K9 PowerOhm
9.20 37683 4056800 PF9F2R37K6 PowerOhm
9.20 47693 6146600 PF9F2R47K6 PowerOhm
9.20 58880 10387700 PF9F2R58K8 PowerOhm
9.20 69635 6672400 PF9F2R69K6 PowerOhm
9.20 90001 9127700 PF9F2R90K0 PowerOhm
9.20 132480 23372300 PF9F2R132K2 PowerOhm
8.00 Ohms
8.00 4232 240700 PR4405-16A PowerOhm
8.00 5408 300200 PR4405-16 PowerOhm
8.00 8192 896100 PR4410-16A PowerOhm
8.00 10368 1303400 PR4410-16 PowerOhm
8.00 14093 401656 442-16A PG/IPC
8.00 16200 2786200 PR442-16A PowerOhm
8.00 16200 2846600 PR442-16 PowerOhm
8.00 21143 693480 442-16 PG/IPC
8.00 23427 1211023 552-18A PG/IPC
8.00 28800 7322900 PR445-16A PowerOhm
8.00 31474 1564893 445-16A PG/IPC
8.00 35138 2494758 552-18 PG/IPC
8.00 39200 10984300 PR552-18 PowerOhm
8.00 41472 4917200 PR445-16 PowerOhm
8.00 46977 2966898 440-16A PG/IPC
8.00 47219 1560331 445-16 PG/IPC
8.00 52321 1559677 555-18A PG/IPC
8.00 57800 19071300 PR555-18A PowerOhm
8.00 64800 10510600 PR440-16 PowerOhm
8.00 70477 3325398 440-16 PG/IPC
8.00 78475 5345909 555-18 PG/IPC
Ohms Watts Watt Seconds Catalog Manufacturer
