130 Rockwell Automation Publication 22C-UM001J-EN-E - January 2017
Appendix B Accessories and Dimensions
480V 50/60 Hz
3-Phase
2.2 3.0 6 6 22C-D6P0N103 C
4.0 5.0 10.5 10.5 22C-D010N103 C
5.5 7.5 12 12 22C-D012N103 C
7.5 10 17 17 22C-D017N103 C
11 15 22 22 22C-D022N103 C
15 20 30 27 22C-D030N103 C
18.5 25 38 38 22C-D038A103 D
22 30 45.5 45.5 22C-D045A103 D
30 40 60 54 22C-D060A103 D
37 50 72 72 22C-D072A103 E
45 60 88 88 22C-D088A103 E
55 75 105 105 22C-D105A103 E
75 100 142 128 22C-D142A103 E
90 125 170 170 22C-D170A103 F
110 150 208 208 22C-D208A103 F
132 200 260 260 22C-D260A103 G
160 250 310 290 22C-D310A103 G
200 300 370 370 22C-D370A103 H
250 350 460 410 22C-D460A103 H
Table 21 - PowerFlex 400 Flange Mount Drives
Drive Ratings Catalog Number Frame
Size
Input Voltage kW HP Output Current (Amps)
45°C 50°C
240V 50/60 Hz
3-Phase
2.2 3 12A 12A 22C-B012F103 C
3.7 5 17.5A 17.5A 22C-B017F103 C
5.5 7.5 24A 24A 22C-B024F103 C
7.5 10 33A 33A 22C-B033F103 C
480V 50/60 Hz
3-Phase
2.2 3 6.0A 6.0A 22C-D6P0F103 C
4.0 5 10A 10A 22C-D010F103 C
5.5 7.5 12A 12A 22C-D012F103 C
7.5 10 17A 17A 22C-D017F103 C
11 15 22A 22A 22C-D022F103
(1)
(1) A DC bus inductor is required. See Tabl e 2 5 for ordering information.
C
15 20 30A 27A 22C-D030F103
(1)
C
Table 20 - PowerFlex 400 Drives
Drive Ratings Catalog Number Frame
Size
Input Voltage Normal Duty Output Current (Amps)
kW HP 45°C 50°C
