Allen-Bradley CompactLogix 1769-L23E-QB1B User Manual

8 CompactLogix Controller
Rockwell Automation Publication 1769-IN082C-EN-P - February 2013
Replacement Parts
These CompactLogix packaged controller replacement parts are available for order.
Required Tools
The only tool required for the installation of the CompactLogix packaged controller is a
medium-sized Phillips-head screwdriver.
Installation Checklist
This table lists tasks that must be completed to fully install and begin using your packaged
controller.
Catalog No. Description Compatible Packaged Controllers
1769-BA CompactLogix controller battery 1769-L23E-QB1B, 1769-L23E-QBFC1B, and
1769-L23-QBFC1B
1769-ECR Compact right end cap 1769-L23E-QB1B, 1769-L23E-QBFC1B, and
1769-L23-QBFC1B
1769-RDQB CompactLogix packaged controller door 1769-L23E-QB1B
1769-RDQBFC CompactLogix packaged controller door 1769-L23E-QBFC1B and 1769-L23-QBFC1B

Installation Tasks
Install the Battery
Connect Expansion Modules (optional)
Panel Mount the System or DIN-rail Mount the System
Grounding Considerations
Wiring Power to the System
Wire the I/O Removable Terminal Blocks
Connect Using the RS-232 Connection
Connect Using the Ethernet Connection
Download and Install EDS Files
Download Packaged Controller Firmware
Use the AutoFlash Feature of RSLogix 5000 Software to Load Firmware
or Use the ControlFLASH Utility to Load Firmware
