16 ControlLogix EtherNet/IP Module
Rockwell Automation Publication 1756-IN606B-EN-P - April 2010
Check Power Supply and Module Status
Check the status indicators and alphanumeric display to determine whether the
power supply and module are operating properly.
Item Description Item Description
1 OK indicator is red during self-test,
then green
3 NET status indicator
2 LINK status indicator 4 Power supply indicator is green
31281-M
LINK NET OK
1
2
3
4
