ControlLogix Voltage/Current Input Module 17
Publication 1756-IN040C-EN-P - October 2000
Calibrated Accuracy at 25°C
Calibration Interval
Better than 0.05% of range - voltage
Better than 0.15% of range - current
Twelve months typical
Input Offset Drift with
Temperature
45µV/degree C
Gain Drift with Temperature 15 ppm/degree C - voltage
20 ppm/degree C - current
Module Error over Full
Temperature Range
0.1% of range - voltage
0.3% of range - current
Module Scan Time for All
Channels (Sample Rate Module
Filter Dependent)
8 pt single ended - 16-488ms
4 pt differential - 8-244ms
2 pt differential - 5-122ms
Module Conversion Method Sigma-Delta
Isolation Voltage
User to system 100% tested at 2550 dc for 1s
Module Keying (Backplane) Electronic
RTB Screw Torque (Cage clamp) 4.4 inch-pounds (0.4Nm)
RTB Keying User defined
RTB and Housing
36 Position RTB (1756-TBCH or TBS6H)
2
Environmental Conditions
Operating Temperature
Storage Temperature
Relative Humidity
0 to 60°C (32 to 140°F)
-40 to 85°C (-40 to 185°F)
5 to 95% noncondensing
Conductors Wire Size
Category
22-14 gauge (2mm
2
) stranded
2
3/64 inch (1.2mm) insulation maximum
2
3, 4
Screwdriver Width for RTB 1/8 inch (3.2mm) maximum
Agency Certification
(when product or
packaging is marked)
1
These specifications are notch filter dependent.
2
Maximum wire size will require extended housing - 1756-TBE.
3
Use this conductor category information for planning conductor routing as described in the system
level installation manual.
4
Refer to publication 1770-4.1 “Industrial Automation Wiring and Grounding Guidelines’.
Marked for all applicable directives
Approved Class I, Division 2, Group A, B, C, D
Certified Process Control Equipment
Certified Class I, Division 2, Group A, B, C, D
Marked for all applicable acts
N223
Listed Industrial Control Equipment
