Allen-Bradley PanelView C600 User Manual

PanelView Component HMI Terminals 31
Publication 2711C-IN001H-EN-P - July 2014
Power
consumption,
max
5 W
(0.21 A @ 24V DC)
7W
(0.28A @ 24V DC)
10 W
(0.42 A @
24V DC)
18 W
(0.75 A @
24V DC)
Weight, approx. Function key:
0.19 kg (0.40 lb)
Keypad:
0.30 kg (0.65 lb)
Keypad:
0.30 kg (0.65 lb)
Touch:
0.20 kg (0.43 lb)
Touch:
0.347 kg (0.76 lb)
Touch:
0.68 kg (1.48 lb)
Touch:
1.57 kg
(3.41 lb)
Dimensions
(HxWxD),
approx.
Function key:
80 x 116 x 54 mm
(3.15 x 4.54 x
2.13 in.)
Keypad:
119 x 139 x 55 mm
(4.69 x 5.47 x
2.15 in.)
Touch:
80 x 116 x 57 mm
(3.15 x 4.54 x
2.23 in.)
Keypad:
119 x 139 x 55 mm
(4.69 x 5.47 x
2.15 in.)
Touch:
113 x 138 x 43 mm
(4.45 x 5.43 x
1.69 in.)
Touch:
154 x 209 x
57 mm
(6.0 x 8.23 x
2.25 in.)
Touch:
250 x 308 x
54 mm (9.84 x
12.13 x
2.13 in.)
General Specifications
Attribute Value
Isolation voltage For 2711C-T4T only
30V (continuous), Basic Insulation Type
Tested @ 500V for 60 s, line to ethernet
No isolation between all ports to line, except ethernet port.
Duration indicates that the product was qualification or type tested to the specified level
(one time tested on a representative sample)
Wire size Single-Wire Gauge: 0.33…2.08 mm
2
(22...14 AWG)
Dual-wire Gauge: 0.33…1.31 mm
2
(22…16 AWG)
Earth wire: 2.08…3.31 mm
2
(14…12 AWG)
Wire type Solid or stranded copper wire rated @ 90 °C (194 °F ), or greater
Wiring category
(1)
1 – on power ports
1 – on communication ports
Enclosure type ratings Meets NEMA/UL Type 4X (indoor) 12, 13, and IEC IP54, IP65 (when marked)
C600 Series B only: NEMA/UL Type 12, 13, and IEC IP54
North American Temp Code T3C – for 2711C-T4T only
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1.
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0…50 °C (32…122 °F)
Temperature, nonoperating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-25…70 °C (-13…158 °F)
PanelView Component - 2711C-F2M, 2711C-K2M, 2711C-T3M, 2711C-K3M, 2711C-T6M,
2711C-T4T, 2711C-T6C, 2711C-T6T, 2711C-T10C
