14 POINT I/O EtherNet/IP Adapter
Publication 1734-IN590A-EN-P - March 2003
Power Supply Specifications
Input Voltage Rating 24V dc nominal
10-28.8V dc range
Field Side Power
Requirements
24V dc (+20% = 28.8V dc maximum) @ 400mA
maximum
Inrush Current 6A maximum for 10ms
Interruption Output voltage will stay within specifications when
input drops out for 10ms at 10V with maximum load.
General Specifications
Indicators 4 red/green status indicators
Adapter status
PointBus status
Network activity status
Network status
2 green power supply status indicators:
System Power (PointBus 5V power)
Field Power (24V from field supply)
Power Consumption 4.5W maximum @ 28.8V dc
Power Dissipation 15.5W maximum @ 28.8V
PointBus Output Current 1A maximum @ 5V dc ±5% (4.75 - 5.25)
Input Overvoltage
Protection
Reverse polarity protected
Thermal Dissipation 9.5 BTU/hr maximum @ 28.8V dc
Isolation Voltage Tested to withstand 1250V rms for 60s
Field Power Bus
Nominal Voltage
Supply Voltage Range
Supply Current
24V dc
10-28.8V dc range,
10A maximum
Dimensions Inches
(Millimeters)
3.0H x 2.16W x 5.25L
(76.2H x 54.9W x 133.4L)
