Allen-Bradley POINT I/O EtherNet/IP 1734-AENT User Manual

Publication 1734-IN590A-EN-P - March 2003 PN 957726-45
Copyright © 2003 Rockwell Automation. All rights reserved. Printed in the U.S.A.
Conductors Wire Size
Category
14- 22 AWG (2.5-0.25mm
2
) solid or stranded wire rated
at 75
o
C or higher
3/64 inch (1.2mm) insulation maximum
2
1
EtherNet Connector RJ-45, Category 5
Terminal Base Screw
Torque
7 pound-inches (0.8Nm)
Mass 9.0 oz/255 grams
Certifications
(when product is
marked)
C-UL-US UL Listed Industrial Control Equipment,
certified for US and Canada
C-UL-US UL Listed for Class I, Division 2, Groups A, B,
C and D Hazardous locations, certified for US
and Canada
CE
2
European Union 89/336/EEC EMC Directive,
compliant with:
EN 61000-6-4; Industrial Emissions
EN 50082-2; Industrial Immunity
EN 61326; Meas./Control/Lab., Industrial
Requirements
EN 61000-6-2; Industrial Immunity
C-Tick
2
Australian Radiocommunications Act,
compliant with:
AS/NZS CISPR 11; Industrial Emissions
ODVA ODVA conformance tested to EtherNet/IP
specifications
1 Use this conductor category information for planning conductor routing as described in publication
1770-4.1, “Industrial Automation Wiring and Grounding Guidelines.”
2 See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates, and
other certification details.

Allen-Bradley POINT I/O EtherNet/IP 1734-AENT Specifications

General

Manufacturer	Allen-Bradley
Product Line	POINT I/O
Catalog Number	1734-AENT
Communication Protocol	EtherNet/IP
Number of Modules	Up to 63
Network Ports	2
Mounting Type	DIN Rail
Network Address	Configurable via software
Number of I/O Modules	Up to 63
Number of Ports	2
Port Type	RJ45
Housing Material	Plastic
Operating Temperature	-20 to 55 °C
