Rockwell Automation Publication 520-UM001G-EN-E - September 2014 113
Programming and Parameters Chapter 3
Advanced Program Group (continued)
A456 [PID 1 Trim Hi]
A468 [PID 2 Trim Hi]
PowerFlex 525 only.
Scales the upper value of the trim frequency when trim is active.
Values Default: 60.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
A457 [PID 1 Trim Lo]
A469 [PID 2 Trim Lo]
PowerFlex 525 only.
Scales the lower value of the trim frequency when trim is active.
Values Default: 0.0 Hz
Min/Max: 0.0/500.0 Hz
Display: 0.1 Hz
A458 [PID 1 Trim Sel]
A470 [PID 2 Trim Sel]
PowerFlex 525 only.
Stop drive before changing this parameter.
Sets the PID output as trim to the source reference.
Options 0 “Disabled” (Default) PID Trim is disabled.
1“TrimOn Pot”
2 “TrimOn Keypd”
3“TrimOn DSI”
4“TrimOn NetOp”
5 “TrimOn 0-10V”
6 “TrimOn 4-20”
7“TrimOn Prset”
8“TrimOn AnMlt”
(1)
9“TrimOn MOP”
10 “TrimOn Pulse”
11 “TrimOn Slgic”
(1)
12 “TrimOn Encdr”
(1)
13 “TrimOn ENet”
(1)
(1) Setting is specific to PowerFlex 525 drives only.
