Allen-Bradley PowerFlex 520 Series

160 Rockwell Automation Publication 520-UM001G-EN-E - September 2014
Appendix A Supplemental Drive Information
Power Specifications
Watts Loss
PowerFlex 520-Series Estimated Watts Loss (Rated Load, Speed & PWM)
Voltage Output Current (A) Total Watts Loss
100...120V,
50/60 Hz 1-Phase
1.6 20.0
2.5 27.0
4.8 53.0
6.0 67.0
200...240V,
50/60 Hz 1-Phase
1.6 20.0
2.5 29.0
4.8 50.0
8.0 81.0
11.0 111.0
200...240V,
50/60 Hz 1-Phase
w/ EMC Filter
1.6 20.0
2.5 29.0
4.8 53.0
8.0 84.0
11.0 116.0
200...240V,
50/60 Hz 3-Phase
1.6 20.0
2.5 29.0
5.0 50.0
8.0 79.0
11.0 107.0
17.5 148.0
24.0 259.0
32.2 323.0
48.3 584.0
62.1 708.0
380...480V,
50/60 Hz 3-Phase
1.4 27.0
2.3 37.0
4.0 62.0
6.0 86.0
10.5 129.0
13.0 170.0
17.0 221.0
24.0 303.0
30.0 387.0
380...480V,
50/60 Hz 3-Phase
w/ EMC Filter
1.4 27.0
2.3 37.0
4.0 63.0
6.0 88.0
10.5 133.0
13.0 175.0
17.0 230.0
24.0 313.0
30.0 402.0
37.0 602.0
43.0 697.0
