Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 141
Programming and Parameters Chapter 3
Parameter Name No. Parameter Name No. Parameter Name No.
EN Rate Act
(1)
685 Fault 5 Time-hr 615 Freq 3 BW
(1)
515
EN Rate Cfg
(1)
141 Fault 5 Time-min 625 Freq 3 Ki
(1)
526
EN Rx Errors
(1)
727 Fault 6 BusVolts
(1)
656 Freq 3 Kp
(1)
525
EN Rx Overruns
(1)
725 Fault 6 Code
(1)
606 Half Bus Enable 549
EN Rx Packets
(1)
726 Fault 6 Current
(1)
646 Home Save
(1)
561
EN Subnet Act 1
(1)
697 Fault 6 Freq
(1)
636 HW Addr 1
(1)
687
EN Subnet Act 2
(1)
698 Fault 6 Time-hr
(1)
616 HW Addr 2
(1)
688
EN Subnet Act 3
(1)
699 Fault 6 Time-min
(1)
626 HW Addr 3v 689
EN Subnet Act 4
(1)
700 Fault 7 BusVolts
(1)
657 HW Addr 4
(1)
690
EN Subnet Cfg 1
(1)
133 Fault 7 Code
(1)
607 HW Addr 5
(1)
691
EN Subnet Cfg 2
(1)
134 Fault 7 Current
(1)
647 HW Addr 6
(1)
692
EN Subnet Cfg 3
(1)
135 Fault 7 Freq
(1)
637 IR Voltage Drop 496
EN Subnet Cfg 4
(1)
136 Fault 7 Time-hr
(1)
617 Jog Accel/Decel 432
EN Tx Errors
(1)
729 Fault 7 Time-min
(1)
627 Jog Frequency 431
EN Tx Packets
(1)
728 Fault 8 BusVolts
(1)
658 Keypad Freq 426
Encoder Pos Tol
(1)
564 Fault 8 Code
(1)
608 Ki Speed Loop
(1)
538
Encoder PPR
(1)
536 Fault 8 Current
(1)
648 Kp Speed Loop
(1)
539
Encoder Speed
(1)
378 Fault 8 Freq
(1)
638 Language 30
Energy Saved 023 Fault 8 Time-hr
(1)
618 Load Loss Level
(1)
490
Enh Control Word
(1)
560 Fault 8 Time-min
(1)
628 Load Loss Time
(1)
491
Fault 1 BusVolts 651 Fault 9 BusVolts
(1)
659 Max Traverse 567
Fault 1 Code 007 Fault 9 Code
(1)
609 Maximum Freq 044
Fault 1 Current 641 Fault 9 Current
(1)
649 Maximum Voltage 534
Fault 1 Freq 631 Fault 9 Freq
(1)
639 Minimum Freq 043
Fault 1 Time-hr 611 Fault 9 Time-hr
(1)
619 MOP Freq 427
Fault 1 Time-min 621 Fault 9 Time-min
(1)
629 MOP Preload 429
Fault 2 BusVolts 652 Fault Clear 551 MOP Reset Sel 428
Fault 2 Code 008 Fault10 BusVolts
(1)
660 MOP Time 430
Fault 2 Current 642 Fault10 Code
(1)
610 Motor Fdbk Type
(1)
535
Fault 2 Freq 632 Fault10 Current
(1)
650 Motor Lm
(1)
499
Fault 2 Time-hr 612 Fault10 Freq
(1)
640 Motor Lx
(1)
500
Fault 2 Time-min 622 Fault10 Time-hr
(1)
620 Motor NP FLA 034
Fault 3 BusVolts 653 Fault10 Time-min
(1)
630 Motor NP Hertz 032
Fault 3 Code 009 Fiber Status 390 Motor NP Poles 035
Fault 3 Current 643 Find Home Dir
(1)
563 Motor NP Power
(1)
037
Fault 3 Freq 633 Find Home Freq
(1)
562 Motor NP RPM 036
Fault 3 Time-hr 613 Flux Current Ref 497 Motor NP Volts 031
Fault 3 Time-min 623 Flying Start En 545 Motor OL Current 033
Fault 4 BusVolts 654 FlyStrt CurLimit 546 Motor OL Level 369
Fault 4 Code 604 Freq 1
(1)
510 Motor OL Ret 494
Fault 4 Current 644 Freq 1 BW
(1)
511 Motor OL Select 493
Fault 4 Freq 634 Freq 1 Ki
(1)
522 Motor Rr
(1)
498
Fault 4 Time-hr 614 Freq 1 Kp
(1)
521 Mtr Options Cfg 573
Fault 4 Time-min 624 Freq 2
(1)
512 MultiDrv Sel 169
Fault 5 BusVolts 655 Freq 2 BW
(1)
513 Opt Data In 1 161
Fault 5 Code 605 Freq 2 Ki
(1)
524 Opt Data In 2 162
Fault 5 Current 645 Freq 2 Kp
(1)
523 Opt Data In 3 163
Fault 5 Freq 635 Freq 3
(1)
514 Opt Data In 4 164
(1) Parameter is specific to PowerFlex 525 drives only.
