Allen-Bradley PowerFlex 520 Series User Manual

162 Rockwell Automation Publication 520-UM001G-EN-E - September 2014
Appendix A Supplemental Drive Information
380...480V AC (-15%, +10%) – 3-Phase Input, 0...460V 3-Phase Output
25A-D1P4N104 25B-D1P4N104 1.4 1.1 0.9 0.7 1.9 1.5 1.2 1.0
25A-D2P3N104 25B-D2P3N104 2.3 1.8 1.5 1.2 3.2 2.6 2.1 1.6
25A-D4P0N104 25B-D4P0N104 4.0 3.2 2.6 2.0 5.7 4.6 3.7 2.9
25A-D6P0N104 25B-D6P0N104 6.0 4.8 3.9 3.0 7.5 6.0 4.9 3.8
25A-D010N104 25B-D010N104 10.5 8.4 6.8 5.3 13.8 11.0 9.0 6.9
25A-D013N104 25B-D013N104 13.0 10.4 8.5 6.5 15.4 12.3 10.0 7.7
25A-D017N104 25B-D017N104 17.0 13.6 11.1 8.5 18.4 14.7 12.0 9.2
25A-D024N104 25B-D024N104 24.0 19.2 15.6 12.0 26.4 21.1 17.2 13.2
25A-D030N104 25B-D030N104 30.0 24.0 19.5 15.0 33.0 26.4 21.5 16.5
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
25A-D1P4N114 25B-D1P4N114 1.4 1.1 0.9 0.7 1.9 1.5 1.2 1.0
25A-D2P3N114 25B-D2P3N114 2.3 1.8 1.5 1.2 3.2 2.6 2.1 1.6
25A-D4P0N114 25B-D4P0N114 4.0 3.2 2.6 2.0 5.7 4.6 3.7 2.9
25A-D6P0N114 25B-D6P0N114 6.0 4.8 3.9 3.0 7.5 6.0 4.9 3.8
25A-D010N114 25B-D010N114 10.5 8.4 6.8 5.3 13.8 11.0 9.0 6.9
25A-D013N114 25B-D013N114 13.0 10.4 8.5 6.5 15.4 12.3 10.0 7.7
25A-D017N114 25B-D017N114 17.0 13.6 11.1 8.5 18.4 14.7 12.0 9.2
25A-D024N114 25B-D024N114 24.0 19.2 15.6 12.0 26.4 21.1 17.2 3.2
25A-D030N114 25B-D030N114 30.0 24.0 19.5 15.0 33.0 26.4 21.5 16.5
25A-D037N114 25B-D037N114 37.0 29.6 24.1 18.5 33.7 27.0 21.9 16.9
25A-D043N114 25B-D043N114 43.0 34.4 28.0 21.5 38.9 31.1 25.3 19.5
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
25A-E0P9N104 25B-E0P9N104 0.9 0.7 0.6 0.5 1.2 1.0 0.8 0.6
25A-E1P7N104 25B-E1P7N104 1.7 1.4 1.1 0.9 2.3 1.8 1.5 1.2
25A-E3P0N104 25B-E3P0N104 3.0 2.4 2.0 1.5 3.8 3.0 2.5 1.9
25A-E4P2N104 25B-E4P2N104 4.2 3.4 2.7 2.1 5.3 4.2 3.4 2.7
25A-E6P6N104 25B-E6P6N104 6.6 5.3 4.3 3.3 8.0 6.4 5.2 4.0
25A-E9P9N104 25B-E9P9N104 9.9 7.9 6.4 5.0 11.2 9.0 7.3 5.6
25A-E012N104 25B-E012N104 12.0 9.6 7.8 6.0 13.5 10.8 8.8 6.8
25A-E019N104 25B-E019N104 19.0 15.2 12.4 9.5 24.0 19.2 15.6 12.0
25A-E022N104 25B-E022N104 22.0 17.6 14.3 11.0 27.3 21.8 17.7 13.7
25A-E027N104 25B-E027N104 27.0 21.6 17.6 13.5 24.7 19.8 16.1 12.4
25A-E032N104 25B-E032N104 32.0 25.6 20.8 16.0 29.2 23.4 19.0 14.6
PowerFlex 520-Series Input Current Scaled By Motor Current
PowerFlex 523 PowerFlex 525 Output Input
Catalog NumberCatalog Number12345678
