Appendix B Accessories and Dimensions
7.5 5.5 7.5 5.5 13.0 323...528 C 25A-D013N104 25B-D013N104
10.0 7.5 10.0 7.5 17.0 323...528 C 25A-D017N104 25B-D017N104
15.0 11.0 15.0 11.0 24.0 323...528 D 25A-D024N104 25B-D024N104
20.0 15.0 15.0 11.0 30.0 323...528 D 25A-D030N104 25B-D030N104
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
0.5 0.4 0.5 0.4 1.4 323...528 A 25A-D1P4N114 25B-D1P4N114
1.0 0.75 1.0 0.75 2.3 323...528 A 25A-D2P3N114 25B-D2P3N114
2.0 1.5 2.0 1.5 4.0 323...528 A 25A-D4P0N114 25B-D4P0N114
3.0 2.2 3.0 2.2 6.0 323...528 A 25A-D6P0N114 25B-D6P0N114
5.0 4.0 5.0 4.0 10.5 323...528 B 25A-D010N114 25B-D010N114
7.5 5.5 7.5 5.5 13.0 323...528 C 25A-D013N114 25B-D013N114
10.0 7.5 10.0 7.5 17.0 323...528 C 25A-D017N114 25B-D017N114
15.0 11.0 15.0 11.0 24.0 323...528 D 25A-D024N114 25B-D024N114
20.0 15.0 15.0 11.0 30.0 323...528 D 25A-D030N114 25B-D030N114
25.0 18.5 20.0 15.0 37.0 323...528 E 25A-D037N114 25B-D037N114
30.0 22.0 25.0 18.5 43.0 323...528 E 25A-D043N114 25B-D043N114
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
0.5 0.4 0.5 0.4 0.9 446...660 A 25A-E0P9N104
(2)
25B-E0P9N104
(2)
1.0 0.75 1.0 0.75 1.7 446...660 A 25A-E1P7N104 25B-E1P7N104
2.0 1.5 2.0 1.5 3.0 446...660 A 25A-E3P0N104 25B-E3P0N104
3.0 2.2 3.0 2.2 4.2 446...660 A 25A-E4P2N104 25B-E4P2N104
5.0 4.0 5.0 4.0 6.6 446...660 B 25A-E6P6N104 25B-E6P6N104
7.5 5.5 7.5 5.5 9.9 446...660 C 25A-E9P9N104 25B-E9P9N104
10.0 7.5 10.0 7.5 12.0 446...660 C 25A-E012N104 25B-E012N104
15.0 11.0 15.0 11.0 19.0 446...660 D 25A-E019N104 25B-E019N104
20.0 15.0 15.0 11.0 22.0 446...660 D 25A-E022N104 25B-E022N104
25.0 18.5 20.0 15.0 27.0 446...660 E 25A-E027N104 25B-E027N104
30.0 22.0 25.0 18.5 32.0 446...660 E 25A-E032N104 25B-E032N104
(1) A non-filtered drive is not available for 380...480V AC 25 HP (18.5 kW) and 30 HP (22.0 kW) ratings. Filtered drives are available,
however you must verify that the application will support a filtered drive.
(2) These drive ratings do not come with a heatsink cooling fan and are in accordance with design specifications.
Dynamic Brake Resistors
Drive Ratings Minimum
Resistance
Ω ±10%
Resistance
Ω ±5% Catalog No.
(1)(2)
Input Voltage HP kW
100...120V
50/60 Hz
1-Phase
0.25 0.2 56 91 AK-R2-091P500
0.5 0.4 56 91 AK-R2-091P500
1.00.755691AK-R2-091P500
1.5 1.1 41 91 AK-R2-091P500
200...240V
50/60 Hz
1-Phase
0.25 0.2 56 91 AK-R2-091P500
0.5 0.4 56 91 AK-R2-091P500
1.00.755691AK-R2-091P500
2.0 1.5 41 91 AK-R2-091P500
3.0 2.2 32 47 AK-R2-047P500
PowerFlex 520-Series Drive Ratings
Output Ratings
Input
Voltage Range
Frame
Size
PowerFlex 523 PowerFlex 525Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW Catalog No. Catalog No.
