Allen-Bradley PowerFlex 520 Series User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 169
Accessories and Dimensions Appendix B
380...480V AC (-15%, +10%) – 3-Phase Input with EMC Filter, 0...460V 3-Phase Output
0.5 0.4 0.5 0.4 1.4 323...528 A 25-PM2-D1P4
1.0 0.75 1.0 0.75 2.3 323...528 A 25-PM2-D2P3
2.0 1.5 2.0 1.5 4.0 323...528 A 25-PM2-D4P0
3.0 2.2 3.0 2.2 6.0 323...528 A 25-PM2-D6P0
5.0 4.0 5.0 4.0 10.5 323...528 B 25-PM2-D010
7.5 5.5 7.5 5.5 13.0 323...528 C 25-PM2-D013
10.0 7.5 10.0 7.5 17.0 323...528 C 25-PM2-D017
15.0 11.0 15.0 11.0 24.0 323...528 D 25-PM2-D024
20.0 15.0 15.0 11.0 30.0 323...528 D 25-PM2-D030
25.0 18.5 20.0 15.0 37.0 323...528 E 25-PM2-D037
30.0 22.0 25.0 18.5 43.0 323...528 E 25-PM2-D043
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
0.5 0.4 0.5 0.4 0.9 446...660 A 25-PM1-E0P9
1.0 0.75 1.0 0.75 1.7 446...660 A 25-PM1-E1P7
2.0 1.5 2.0 1.5 3.0 446...660 A 25-PM1-E3P0
3.0 2.2 3.0 2.2 4.2 446...660 A 25-PM1-E4P2
5.0 4.0 5.0 4.0 6.6 446...660 B 25-PM1-E6P6
7.5 5.5 7.5 5.5 9.9 446...660 C 25-PM1-E9P9
10.0 7.5 10.0 7.5 12.0 446...660 C 25-PM1-E012
15.0 11.0 15.0 11.0 19.0 446...660 D 25-PM1-E019
20.0 15.0 15.0 11.0 22.0 446...660 D 25-PM1-E022
25.0 18.5 20.0 15.0 27.0 446...660 E 25-PM1-E027
30.0 22.0 25.0 18.5 32.0 446...660 E 25-PM1-E032
PowerFlex 520-Series Control Module
Item Description
Frame
Size Catalog No.
PowerFlex 523 Control
Module
Replacement control module for use with
PowerFlex 520-Series drives. Includes:
• Control Module
• Control Module Front Cover
A...E 25A-CTM1
PowerFlex 525 Control
Module
25B-CTM1
Other Parts
Item Description
Frame
Size Catalog No.
PowerFlex 523 Control
Module Front Cover
Replacement cover for the control module I/O terminals,
EtherNet/IP and DSI ports.
A...E 25A-CTMFC1
PowerFlex 525 Control
Module Front Cover
25B-CTMFC1
PowerFlex 520-Series
Power Module Front Cover
Replacement cover for the PowerFlex 520-Series power
module.
B 25-PMFC-FB
C 25-PMFC-FC
D 25-PMFC-FD
E 25-PMFC-FE
PowerFlex 520-Series
Power Terminal Guard
Replacement finger guard for power terminals. A 25-PTG1-FA
B 25-PTG1-FB
C 25-PTG1-FC
D 25-PTG1-FD
E 25-PTG1-FE
Output Ratings
Input
Voltage Range
Frame
Size Catalog No.
Normal Duty Heavy Duty
Output
Current (A)HP kW HP kW
