Rockwell Automation Publication 520-QS001A-EN-E - March 2014 7
PowerFlex 520-Series Adjustable Frequency AC Drive
25A-D013N114 25B-D013N114 7.5 5.5 7.5 5.5 13.0 323...528 14.1 15.4 20/35 100-C23 140M-D8E-C20 – 175.0
25A-D017N114 25B-D017N114 10.0 7.5 10.0 7.5 17.0 323...528 16.8 18.4 25/40 100-C23 140M-D8E-C20 – 230.0
25A-D024N114 25B-D024N114 15.0 11.0 15.0 11.0 24.0 323...528 24.1 26.4 35/63 100-C37 140M-F8E-C32 656.7
(7)
313.0
25A-D030N114 25B-D030N114 20.0 15.0 15.0 11.0 30.0 323...528 30.2 33.0 45/70 100-C43 140M-F8E-C45 656.7
(7)
402.0
25A-D037N114 25B-D037N114 25.0 18.5 20.0 15.0 37.0 323...528 30.8 33.7 45/70 100-C43 140M-F8E-C45 – 602.0
25A-D043N114 25B-D043N114 30.0 22.0 25.0 18.5 43.0 323...528 35.6 38.9 50/80 100-C60 140M-F8E-C45 – 697.0
525...600V AC (-15%, +10%) – 3-Phase Input, 0...575V 3-Phase Output
25A-E0P9N104 25B-E0P9N104 0.5 0.4 0.5 0.4 0.9 446...660 1.4 1.2 3/6 100-C09 140M-C2E-B25 – 22.0
25A-E1P7N104 25B-E1P7N104 1.0 0.75 1.0 0.75 1.7 446...660 2.6 2.3 3/6 100-C09 140M-C2E-B25 – 32.0
25A-E3P0N104 25B-E3P0N104 2.0 1.5 2.0 1.5 3.0 446...660 4.3 3.8 6/10 100-C09 140M-C2E-B40 – 50.0
25A-E4P2N104 25B-E4P2N104 3.0 2.2 3.0 2.2 4.2 446...660 6.1 5.3 10/16 100-C09 140M-D8E-B63 – 65.0
25A-E6P6N104 25B-E6P6N104 5.0 4.0 5.0 4.0 6.6 446...660 9.1 8.0 10/20 100-C09 140M-D8E-C10 – 95.0
25A-E9P9N104 25B-E9P9N104 7.5 5.5 7.5 5.5 9.9 446...660 12.8 11.2 16/25 100-C16 140M-D8E-C16
(6)
– 138.0
25A-E012N104 25B-E012N104 10.0 7.5 10.0 7.5 12.0 446...660 15.4 13.5 20/32 100-C23 140M-D8E-C16 – 164.0
25A-E019N104 25B-E019N104 15.0 11.0 15.0 11.0 19.0 446...660 27.4 24.0 32/50 100-C30 140M-F8E-C25 656.7
(7)
290.0
25A-E022N104 25B-E022N104 20.0 15.0 15.0 11.0 22.0 446...660 31.2 27.3 35/63 100-C30 140M-F8E-C32 656.7
(7)
336.0
25A-E027N104 25B-E027N104 25.0 18.5 20.0 15.0 27.0 446...660 28.2 24.7 35/50 100-C30 140M-F8E-C32 1416.0
(7)
466.0
25A-E032N104 25B-E032N104 30.0 22.0 25.0 18.5 32.0 446...660 33.4 29.2 40/63 100-C37 140M-F8E-C32 1416.0
(7)
562.0
(1) Normal Duty (ND) and Heavy Duty (HD) ratings are available for this drive.
(2) When the drive is controlling motors with lower amp ratings, refer to the drive nameplate for drive input current rating.
(3) The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See Bulletin 140M Motor Protection Circuit Breakers Application Ratings.
(4) Bulletin 140M with adjustable current range should have the current trip set to the minimum range that the device will not trip.
(5) Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 480Y/277 and 600Y/347 AC input. Not UL listed for use on 480V or 600V Delta/Delta, corner ground, or high-resistance ground
systems.
(6) When used with the 140M circuit breaker, the 25A-E9P9104 must be installed in a ventilated or non-ventilated enclosure with the minimum size of 457.2 x 457.2 x 269.8 mm (18 x 18 x 10.62 in.).
(7) When using a Manual Self-Protected (Type E) Combination Motor Controller with this drive power rating, the drive must be installed in a ventilated or non-ventilated enclosure with the minimum volume
specified in this column. Application specific thermal considerations may require a larger enclosure.
Catalog No.
(1)
Output Ratings Input Ratings Branch Circuit Protection
Min. Enclosure
Volume (in.
3
)
IP 20 Open Type
Watts Loss
PowerFlex
523
PowerFlex
525
Normal Duty Heavy Duty
Amps
Voltage
Range kVA
Max
Amps
(2)
Fuse
Ratings
Min/Max Contactors
140M Motor
Protectors
(3)
(4)
(5)
HP kW HP kW
