Allen-Bradley PowerFlex 525 - Technical Specifications

8 Rockwell Automation Publication 520-QS001A-EN-E - March 2014
PowerFlex 520-Series Adjustable Frequency AC Drive
Technical Specifications
PowerFlex 523 Specifications
Input/Output Ratings Digital Control Inputs (Input Current = 6 mA) Approvals
Output Frequency: 0...500 Hz (Programmable)
Efficiency: 97.5% (Typical)
SRC (Source) Mode:
18...24V = ON
0...6V = OFF
SNK (Sink) Mode:
0...6V = ON
18...24V = OFF
Control Output Analog Control Inputs Fuses and Circuit Breakers
Programmable Output, Form C
Resistive Rating: 3.0 A @ 30V DC, 125V AC and 240V AC
Inductive Rating: 0.5 A @ 30V DC, 125V AC and 240V AC
4-20 mA Analog: 250 Ω input impedance
0-10V DC Analog: 100 kΩ input impedance
External Pot: 1...10 kΩ, 2 W min.
Recommended Fuse Type:
UL Class CC, J, T or Type BS88; 600V (550V) or equivalent.
Recommended Circuit Breakers: HMCP or equivalent.
Protective Features
Motor Protection: I
2
t overload protection – 150% for 60 s, 200% for 3 s (Provides Class 10 protection)
Overcurrent: 200% hardware limit, 300% instantaneous fault
Over Voltage: 100...120V AC Input – Trip occurs @ 405V DC bus voltage (equivalent to 150V AC incoming line)
200...240V AC Input – Trip occurs @ 405V DC bus voltage (equivalent to 290V AC incoming line)
380...480V AC Input – Trip occurs @ 810V DC bus voltage (equivalent to 575V AC incoming line)
525...600V AC Input – Trip occurs @ 1005V DC bus voltage (equivalent to 711V AC incoming line)
Under Voltage: 100...120V AC Input – Trip occurs @ 190V DC bus voltage (equivalent to 75V AC incoming line)
200...240V AC Input – Trip occurs @ 190V DC bus voltage (equivalent to 150V AC incoming line)
380...480V AC Input – Trip occurs @ 390V DC bus voltage (equivalent to 275V AC incoming line)
525...600V AC Input – If P038 = 3 “600V” trip occurs @ 487V DC bus voltage (344V AC incoming line);
– If P038 = 2 “480V” trip occurs @ 390V DC bus voltage (275V AC incoming line)
Control Ride Through: Minimum ride through is 0.5 s - typical value 2 s
Faultless Power Ride Through: 100 ms
PowerFlex 525 Specifications
Input/Output Ratings Approvals
Output Frequency: 0...500 Hz (Programmable)
Efficiency: 97.5% (Typical)
Digital Control Inputs (Input Current = 6 mA) Analog Control Inputs Fuses and Circuit Breakers
SRC (Source) Mode:
18...24V = ON
0...6V = OFF
SNK (Sink) Mode:
0...6V = ON
18...24V = OFF
4-20 mA Analog: 250 Ω input impedance
0-10V DC Analog: 100 kΩ input impedance
External Pot: 1...10 kΩ, 2 W min.
Recommended Fuse Type:
UL Class J, T or Type BS88; 600V (550V) or equivalent.
Recommended Circuit Breakers: HMCP or equivalent.
Control Output
Programmable Output, Form A and Form B
Resistive Rating: 3.0 A @ 30V DC, 125V AC and 240V AC
Inductive Rating: 0.5 A @ 30V DC, 125V AC and 240V AC
Opto Outputs
30V DC, 50 mA
Non-inductive
Analog Outputs (10-bit)
0-10V: 1 kΩ min.
4-20 mA: 525 Ω max.
Protective Features
Motor Protection: I
2
t overload protection – 150% for 60 s, 200% for 3 s (Provides Class 10 protection)
Overcurrent: 200% hardware limit, 300% instantaneous fault
Over Voltage: 100...120V AC Input – Trip occurs @ 405V DC bus voltage (equivalent to 150V AC incoming line)
200...240V AC Input – Trip occurs @ 405V DC bus voltage (equivalent to 290V AC incoming line)
380...480V AC Input – Trip occurs @ 810V DC bus voltage (equivalent to 575V AC incoming line)
525...600V AC Input – Trip occurs @ 1005V DC bus voltage (equivalent to 711V AC incoming line)
Under Voltage: 100...120V AC Input – Trip occurs @ 190V DC bus voltage (equivalent to 75V AC incoming line)
200...240V AC Input – Trip occurs @ 190V DC bus voltage (equivalent to 150V AC incoming line)
380...480V AC Input – Trip occurs @ 390V DC bus voltage (equivalent to 275V AC incoming line)
525...600V AC Input – If P038 = 3 “600V” trip occurs @ 487V DC bus voltage (344V AC incoming line);
– If P038 = 2 “480V” trip occurs @ 390V DC bus voltage (275V AC incoming line)
Control Ride Through: Minimum ride through is 0.5 s – typical value 2 s
Faultless Power Ride Through: 100 ms
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
UL508C
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
C
CSA 22.2
LV Directive 2006/95/EC: EN 61800-5-1
EMC Directive 2004/108/EC: EN 61800-3:2004
N223
AC156
KCC: Article 58-2 of Radio Waves Act, Clause 3
GOST-R: POCC US.ME92.H00040
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
UL508C
U
L
®
L
I
S
T
E
D
9
6
6
X
I
N
D
C
O
N
T
E
Q
C
CSA 22.2
LV Directive 2006/95/EC: EN 61800-5-1
EMC Directive 2004/108/EC: EN 61800-3:2004
N223
AC156
KCC: Article 58-2 of Radio Waves Act, Clause 3
GOST-R: POCC US.ME92.H00040
TUV
Rheinland
..
Functional
Safety
Bauart geprüft
Type approved
II (2) G D
