Allen-Bradley PowerFlex 527 Reference Manual

Chapter 3
Interpret the Attribute Tables
120 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
ID Access
Rule
Attribute Name B E F P V T Conditional Implementation
1320 Set Motor Rated Peak Current - N Y Y Y O-IM
697 Set Motor Thermal Overload User Limit - N N N N
1315 Set Motor Type - R R R R O-Enum
1 = Rotary Permanent Magnet (Y)
2 = Rotary Induction (N)
3 = Linear Permanent Magnet (N)
4 = Linear Induction (N)
1325 Set Motor Winding to Ambient Capacitance - N Y Y Y
1326 Set Motor Winding to Ambient Resistance - N Y Y Y
521 Get Operative Current Limit - - Y Y Y
600 Get Output Frequency - R N N N
508 Set Overtorque Limit - N Y Y Y
509 Set Overtorque Limit Time - N Y Y Y
2310 Set PM Motor Flux Saturation - N Y Y Y
1343 Set PM Motor Force Constant - N Y Y Y Rotary PM Motor only
1342 Set PM Motor Rated Force - N Y Y Y Rotary PM Motor only
1339 Set PM Motor Rated Torque - N Y Y Y Rotary PM Motor only
1340 Set PM Motor Torque Constant - - Y Y Y Rotary PM Motor only
445 Set Position Error Tolerance Time - - Y - -
365 Get Position Fine Command - - Y - -
446 Set Position Integrator Control - - R - - O-Bits
1: Auto-Preset (N)
447 Set Position Integrator Preload - - N - -
781 Set Position Lead Lag Filter Bandwidth - - N - -
782 Set Position Lead Lag Filter Gain - - N - -
783 Set Position Notch Filter Frequency - - Y - -
627 Set Power Loss Action - N N N N O-Enum
2 = Decel Regen (N)
628 Set Power Loss Threshold - N N N N
630 Set Power Loss Time - N N N N
376 Set* Ramp Acceleration - N - N - Derived
377 Set* Ramp Deceleration - N - N - Derived
378 Set Ramp Jerk Control - N - N -
375 Set* Ramp Velocity - Negative - N - N - Derived
374 Set* Ramp Velocity - Positive - N - N - Derived
613/354 Set Resistive Brake Contact Delay - N N N N PM Motor only
1333 Set Rotary Motor Damping Coefficient - N N N N Rotary Motor only
2312 Set Rotary Motor Fan Cooling Derating - N N N N Rotary Motor only
2311 Set Rotary Motor Fan Cooling Speed - N N N N Rotary Motor only
1330 Set Rotary Motor Inertia - - Y Y Y Rotary Motor only
1332 Set Rotary Motor Max Speed - - Y Y Y Rotary Motor only
