Allen-Bradley PowerFlex 70 Quick Start Quide

English-12 PowerFlex 70 Adjustable Frequency AC Drive Quick Start
SPEED COMMAND (File C)
Speed References
090 [Speed Ref A Sel]
Selects the source of the speed
reference to the drive unless [Speed Ref
B Sel] or [Preset Speed 1-7] is selected.
For more information on selecting a
speed reference source, refer to the
PowerFlex 70 User Manual, “Speed
Reference Control”.
(1)
See Appendix B of the User Manual
for DPI port locations.
(2)
Enhanced Control Drives Only.
Default:
Options:
2
1
2
3-8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23-
29
30
“Analog In 2”
“Analog In 1”
“Analog In 2”
“Reserved”
“MOP Level”
“Reserved”
“Preset Spd1”
“Preset Spd2”
“Preset Spd3”
“Preset Spd4”
“Preset Spd5”
“Preset Spd6”
“Preset Spd7”
“DPI Port 1”
(1)
“DPI Port 2”
(1)
“DPI Port 3”
(1)
“Reserved”
“DPI Port 5”
(1)
“Reserved”
“HighRes Ref”
(2)
002
091
thru
093
101
thru
107
117
thru
120
192
thru
194
213
272
273
320
361
thru
366
091 [Speed Ref A Hi]
Scales the upper value of the [Speed Ref
A Sel] selection when the source is an
analog input.
Default:
Min/Max:
Units:
[Maximum Speed]
–/+[Maximum Speed]
0.1 Hz
082
092 [Speed Ref A Lo]
Scales the lower value of the [Speed Ref
A Sel] selection when the source is an
analog input.
Default:
Min/Max:
Units:
0.0 Hz
–/+[Maximum Speed]
0.1 Hz
081
Discrete Speeds
101
102
103
104
105
106
107
[Preset Speed 1]
[Preset Speed 2]
[Preset Speed 3]
[Preset Speed 4]
[Preset Speed 5]
[Preset Speed 6]
[Preset Speed 7]
Provides an internal fixed speed
command value. In bipolar mode
direction is commanded by the sign of
the reference.
Default:
Min/Max:
Units:
5.0 Hz
10.0 Hz
20.0 Hz
30.0 Hz
40.0 Hz
50.0 Hz
60.0 Hz
–/+[Maximum Speed]
0.1 Hz
090
093
DYNAMIC CONTROL (File D)
Ramp Rates
140
141
[Accel Time 1]
[Accel Time 2]
Sets the rate of accel for all speed
increases.
Default:
Min/Max:
Units:
10.0 Secs
10.0 Secs
0.1/3600.0 Secs
0.1 Secs
142
143
146
361
thru
366
142
143
[Decel Time 1]
[Decel Time 2]
Sets the rate of decel for all speed
decreases.
Default:
Min/Max:
Units:
10.0 Secs
10.0 Secs
0.1/3600.0 Secs
0.1 Secs
140
141
146
361
thru
366
Max Speed
Accel Time
Accel Rate
=
Max Speed
Decel Time
Decel Rate
=
