2-106 Fuses and Circuit Breakers
Table 2.V PF700 540 Volt DC Input Protection Devices
Table 2.W PF700 650 Volt DC Input Protection Devices
Drive
Catalog
Number
Frame
kW
Rating
DC Input
Ratings Output Amps
Fuse Bussmann Style FuseND HD Amps kW Cont. 1 Min. 3 Sec.
540 Volt DC Input
20BC1P3 1 0.37 0.25 1.3 0.7 1.3 1.4 1.9 3 BUSSMANN_JKS-3
20BC2P1 1 0.75 0.55 2.1 1.1 2.1 2.4 3.2 6 BUSSMANN_JKS-6
20BC3P5 1 1.5 0.75 3.7 2.0 3.5 4.5 6.0 8 BUSSMANN_JKS-8
20BC5P0 1 2.2 1.5 5.3 2.9 5.0 5.5 7.5 10 BUSSMANN_JKS-10
20BC8P7 1 4 3.0 9.3 5.0 8.7 9.9 13.2 20 BUSSMANN_JKS-20
20BC011 1 5.5 4 12.6 6.8 11.5 13 17.4 25 BUSSMANN_JKS-25
20BC015 1 7.5 5.5 16.8 9.1 15.4 17.2 23.1 30 BUSSMANN_JKS-30
20BC022 1 11 7.5 24 13 22 24.2 33 45 BUSSMANN_JKS-45
20BC030 2 15 11 33.2 17.9 30 33 45 60 BUSSMANN_JKS-60
20BC037 2 18.5 15 40.9 22.1 37 45 60 80 BUSSMANN_JKS-80
20BC043 3 22 18.5 47.5 25.7 43 56 74 90 BUSSMANN_JKS-90
20BC056 3 30 22 61.9 33.4 56 64 86 110 BUSSMANN_JKS-110
20BC072 3 37 30 80.5 43.5 72 84 112 150 BUSSMANN_JKS-150
20BC085 4 – 37 80.5 43.5 72 108 144 150 BUSSMANN_JKS-150
45 – 95.1 51.3 85 94 128 200
BUSSMANN_JKS-200
20BH105
(1)
(1)
Also applies to “P” voltage class.
5 – 45 95.1 51.3 85 128 170 200 BUSSMANN_JKS-200
55 – 117.4 63.4 105 116 158 200 BUSSMANN_JKS-200
20BH125
(1)
5 – 45 91.9 63.7 96 144 168 150
55 – 139.8 75.5 125 138 163 225
BUSSMANN_JKS-225
20BH140
(1)
6 – 55 117.4 63.4 105 158 210 200 BUSSMANN_JKS-200
75 – 158.4 85.6 140 154 210 300 BUSSMANN_JKS-300
20DH170
(1)
6 – 75 158.4 85.6 140 210 280 300 BUSSMANN_JKS-300
90 – 192.4 103.9 170 187 255 350
BUSSMANN_JKS-350
20DH205
(1)
6 – 90 192.4 103.9 170 255 313 350 BUSSMANN_JKS-350
110 – 232 125.3 205 220 289 400 BUSSMANN_JKS-400
Drive
Catalog
Number
Frame
kW
Rating
DC Input
Ratings Output Amps
Fuse Bussmann Style FuseND HD Amps kW Cont. 1 Min. 3 Sec.
650 Volt DC Input
20BD1P1 0 0.5 0.33 1.0 0.6 1.1 1.2 1.6 6 BUSSMANN_JKS-6
20BD2P1 0 1 0.75 1.9 1.2 2.1 2.4 3.2 6 BUSSMANN_JKS-6
20BD3P4 0 2 1.5 3.0 2.0 3.4 4.5 6.0 6 BUSSMANN_JKS-6
20BD5P0 0 3 2 4.5 2.9 5.0 5.5 7.5 10 BUSSMANN_JKS-10
20BD8P0 0 5 3 8.1 5.2 8.0 8.8 12 15 BUSSMANN_JKS-15
20BD011 0 7.5 5 11.1 7.2 11 12.1 16.5 20 BUSSMANN_JKS-20
20BD014 1 10 7.5 14.7 9.5 14 16.5 22 30 BUSSMANN_JKS-30
20BD022 1 15 10 23.3 15.1 22 24.2 33 45 BUSSMANN_JKS-45
20BD027 2 20 15 28.9 18.8 27 33 44 60 BUSSMANN_JKS-60
20BD034 2 25 20 36.4 23.6 34 40.5 54 70 BUSSMANN_JKS-70
20BD040 3 30 25 42.9 27.8 40 51 68 80 BUSSMANN_JKS-80
20BD052 3 40 30 55.7 36.1 52 60 80 100 BUSSMANN_JKS-100
20BD065 3 50 40 69.7 45.4 65 78 104 150 BUSSMANN_JKS-150
20BR077
(1)
(1)
Also applies to “J” voltage class.
4 – 50 67.9 45.4 65 98 130 150 BUSSMANN_JKS-150
4 60 – 84.5 54.7 77 85 116 150 BUSSMANN_JKS-150
20BR096
(1)
5 – 60 84.5 54.7 77 116 154 150 BUSSMANN_JKS-150
75 – 105.3 68.3 96 106 144 200 BUSSMANN_JKS-200
20BR125
(1)
5 – 75 105.3 68.3 96 144 168 200 BUSSMANN_JKS-200
100 – 137.1 88.9 125 138 163 250 BUSSMANN_JKS-250
20BR156
(1)
6 – 100 137.1 88.9 125 188 250 250 BUSSMANN_JKS-250
125 – 171.2 110.9 156 172 234 300 BUSSMANN_JKS-300
20BR180
(1)
6 – 125 171.2 110.9 156 234 312 300 BUSSMANN_JKS-300
150 – 204.1 132.2 180 198 270 400 BUSSMANN_JKS-400
