Allen-Bradley powerflex 700 Reference Manual

1-10 PowerFlex 70 Dimensions
Figure 1.4 PowerFlex 70 Flange Mount Bottom View Dimensions
Frame Dimensions in millimeters and (inches)
A
B
C
D
72.4 (2.85)
59.6 (2.35)
96.1 (3.78)
101.9 (4.01)
40.7 (1.60)
51.3 (2.02)
103.2 (4.06)
22.2 (0.87) Dia.
4 Places
43.2
(1.70)
70.5
(2.78)
76.6
(3.02)
95.9
(3.78)
104.4
(4.11)
70.9 (2.79)
92.4 (3.64)
102.7 (4.04)
130.5 (5.14)
140.6 (5.54)
144.4 (5.69)
60.3 (2.37)
49.7 (1.96)
41.4
(1.63)
65.9
(2.59)
76.6
(3.02)
95.0
(3.74)
103.5
(4.07)
22.2 (0.87) Dia.
5 Places
53.1 (2.09)
73.0 (2.87)
92.2 (3.63)
111.2 (4.38)
64.7 (2.55)
75.4 (2.97)
129.3 (5.09)
40.6
(1.60)
68.7
(2.70)
94.6
(3.72)
102.9
(4.05)
22.2 (0.87) Dia.
4 Places
51.9 (2.04)
78.3 (3.08)
107.3 (4.22)
135.5 (5.33)
164.1 (6.46)
83.7 (3.30)
73.0 (2.87)
42.3
(1.67)
74.1
(2.92)
94.6
(3.27)
103.5
(4.07)
28.5 (1.12) Dia.
2 Places
22.2 (0.87) Dia.
2 Places

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
