PowerFlex 700 Technical Data
20B-TD001F-EN-P 45
PowerFlex 700 (Standard/Vector), 690V Shielded/Unshielded Cable - Meters (Feet)
4 60 2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200)
1321-RWR80-EP
●
4 36.6 (120) 137.2 (450) 45.7 (150) 152.4 (500) 274.3 (900) 365.8 (1200)
1321-RWR80-EP
5 75 2 42.7 (140) 182.9 (600) 152.4 (500) 365.8 (1200) 365.8 (1200) 365.8 (1200)
1321-RWR80-EP
●
4 36.6 (120) 137.2 (450) 45.7 (150) 152.4 (500) 274.3 (900) 365.8 (1200)
1321-RWR80-EP
100 2 42.7 (140) 182.9 (600) 152.4 (500) 304.8 (1000) 365.8 (1200) 365.8 (1200)
1321-RWR100-EP
●
4 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 274.3 (900) 365.8 (1200)
1321-RWR100-EP
6 125 2 42.7 (140) 182.9 (600) 121.9 (400) 304.8 (1000) 365.8 (1200) 365.8 (1200)
1321-RWR130-EP
●
4 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 228.6 (750) 365.8 (1200)
1321-RWR130-EP
150 2 42.7 (140) 182.9 (600) 121.9 (400) 304.8 (1000) 365.8 (1200) 365.8 (1200)
1321-RWR160-EP
●
4 42.7 (140) 137.2 (450) 45.7 (150) 152.4 (500) 198.1 (650) 365.8 (1200)
1321-RWR160-EP
Frame
Rating No Solution Reactor Only Reactor + Damping Resistor Reactor Resistor Available Options
kW kHz 1850V 2000V 1850V 2000V 1850V 2000V Cat. No. Ohms Watts
TFA1 TFB2 RWR2 RWC
4 45 2 30.5 (100) 106.9 (350) 91.4 (300) 152.4 (500) 365.8 (1200) 365.8 (1200)
1321-3R80-C
50 345
4 24.4 (80) 76.2 (250) 36.6 (120) 121.9 (400) 213.4 (700) 274.3 (900)
1321-3R80-C
50 690
55 2 30.5 (100) 106.9 (350) 91.4 (300) 152.4 (500) 365.8 (1200) 365.8 (1200)
1321-3R80-C
50 345
4 24.4 (80) 76.2 (250) 36.6 (120) 106.9 (350) 213.4 (700) 274.3 (900)
1321-3R80-C
50 690
5 75 2 30.5 (100) 106.9 (350) 91.4 (300) 152.4 (500) 365.8 (1200) 365.8 (1200)
1321-3R100-C
50 345
4 30.5 (100) 76.2 (250) 36.6 (120) 106.9 (350) 213.4 (700) 274.3 (900)
1321-3R100-C
50 690
90 2 30.5 (100) 106.9 (350) 91.4 (300) 152.4 (500) 365.8 (1200) 365.8 (1200)
1321-3R130-C
50 375
4 30.5 (100) 76.2 (250) 36.6 (120) 106.9 (350) 182.9 (600) 274.3 (900)
1321-3R130-C
50 750
6 110 2 30.5 (100) 106.9 (350) 91.4 (300) 152.4 (500) 365.8 (1200) 365.8 (1200)
1321-3R160-C
50 375
4 30.5 (100) 76.2 (250) 36.6 (120) 99.1 (325) 152.4 (500) 274.3 (900)
1321-3R160-C
50 750
132 2 30.5 (100) 106.9 (350) 91.4 (300) 152.4 (500) 365.8 (1200) 365.8 (1200)
1321-3R200-C
50 375
4 30.5 (100) 76.2 (250) 36.6 (120) 83.8 (275) 152.4 (500) 274.3 (900)
1321-3R200-C
50 750
Frame
Rating No Solution Reactor Only 1321-RWR RWR Available Options
Hp kHz 1488V 1850V 1488V 1850V 1488V 1850V Cat. No.
TFA1 TFB2 RWR2 RWC

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
