PowerFlex 700 Technical Data
6 20B-TD001F-EN-P
c4
ND Rating
600V, 60 Hz Input
Code Amps Hp Frame
1P7 1.7 1.0 0
2P7 2.7 2.0 0
3P9 3.9 3.0 0
6P1 6.1 5.0 0
9P0 9.0 7.5 0
011 11 10 1
017 17 15 1
022 22 20 2
027 27 25 2
032 32 30 3
041 41 40 3
052 52 50 3
062 62 60 4
077 77 75 5
099 99 100 5
125 125 125 6
144 144 150 6
c5
ND Rating
690V, 50 Hz Input
Code Amps kW Frame
052 52 45 5
060 60 55 5
082 82 75 5
098 98 90 6
119 119 110 6
142 142 132 6
d
Enclosure
Code Enclosure
A IP20, NEMA/UL Type 1
F
Open/Flange Mount
Front: IP00, NEMA/UL Type Open
Back/Heatsink: IP54, NEMA Type 12
N §
Open/Flange Mount
Front: IP00, NEMA/UL Type Open
Back/Heatsink: IP54, NEMA 12
G
Stand-Alone/Wall Mount
IP54, NEMA/UL Type 12
J
IP00, NEMA/UL Type Open with
Conformal Coat
M
IP20, NEMA/UL Type 1 with Conformal
Coat
U
Roll-In
Front: IP00, NEMA/UL Type Open
Back/Heatsink: IP54, NEMA 12
Frames 8 & 9 Only
V
Roll-In with Conformal Coat
Front: IP00, NEMA/UL Type Open
Back/Heatsink: IP54, NEMA 12
Frames 8 & 9 Only
Only available for Frame 5 & Frame 6 drives,
400…690V.
§ Only available for Frames 7…10.
Only available with Vector Control option.
e
HIM
Code Operator Interface
0 Blank Cover
3 Full Numeric LCD
5 Prog. Only LCD
J
Remote (Panel Mount), IP66, NEMA/UL
Type 12 Full Numeric LCD HIM
K
Remote (Panel Mount), IP66, NEMA/UL
Type 12 Prog. Only LCD HIM
Available with Frames 5…6 Stand-Alone IP54
drives (Enclosure Code "G").
f
Documentation
Code Type
A Manual
N No Manual
Q
No Shipping Package
(Internal Use Only)
g
Brake
Code
w/Brake IGBT
YYes
NNo
Brake IGBT is standard on Frames 0-3,
optional on Frames 4-6 and not available on
Frames 7…10.
h
Internal Braking Resistor
Code w/Resistor
Y
Yes
NNo
Not available for Frame 3 drives or larger.
i
Emission
Code CE Filter
‡ CM Choke
A Yes Yes
B ♠
Yes No
NNoNo
‡ Note: 600V class drives below 77 Amps
(Frames 0-4) are declared to meet the Low
Voltage Directive. It is the responsibility of the
user to determine compliance to the EMC
directive. Frames 7…10, 400/480V AC drives
(Voltage Rating codes "C" and "D") meet CE
certification requirements when installed per
recommendations.
Refer to Internal EMC Filter for details on
selecting this option for each frame size.
♠ Only available for 208…240V Frame 0-3 drives.
j
Comm Slot
Code Network Type
B BACnet MS/TP
C ControlNet (Coax)
D DeviceNet
E EtherNet/IP
R Remote I/O
S RS485 DF1
NNone
k
Control & I/O
Code Control I/O Volts
A Standard 24V DC/AC
B Standard 115V AC
C
Vector
♣
24V DC
D
Vector
♣
115V AC
N Standard None
♣ Vector Control Option utilizes DPI Only. Frame
7…10 drives only accept Vector Control.
l
Feedback
Code Type
0None
1 Encoder, 12V/5V
m
Future Use
n
Special Firmware (Frames 0…6 Only)
Code Type
AD
60 Hz Maximum
AE
Cascading Fan/Pump Control
AX
82 Hz Maximum
BA
Pump Off (for pump jack)
Must be used with Vector Control option C or
D (Position k). Positions m-n are only required
when custom firmware is supplied.
