PowerFlex 700 Technical Data
20B-TD001F-EN-P 9
Internal Dynamic Brake Resistor Kits
These resistors have a limited duty cycle. Refer to the PowerFlex
Dynamic Braking Selection Guide to determine if an internal
resistor will be sufficient for your application. An external resistor
may be required.
Drive Input
Voltage
Brake Resistance
Frame
Cat. No.
Ω
208…240V AC
62 0
20BB-DB1-0
62 1 (2…5 Hp)
20BB-DB1-1
22 1 (7.5 Hp)
20BB-DB2-1
22 2
20BB-DB1-2
380…600V AC
115 0
20BD-DB1-0
115 1
20BD-DB1-1
380…480V AC 68 2
20BD-DB1-2
§ Discount Schedule C2.
Dynamic Brake, Chopper Only Kits
Description Rating Cat. No.
200…240V AC
18A 1336-WA018
70A 1336-WA070
115A 1336-WA115
380…480V AC
9A 1336-WB009
35A 1336-WB035
110A 1336-WB110
500…600V AC
9A 1336-WC009
35A 1336-WC035
85A 1336-WC085
Terminators
Description
Cat. No.
for use with 3.7 kW (5 Hp) & below drives
1204-TFA1
for use with 1.5 kW (2 Hp) & up drives
1204-TFB2
See Appendix A of publication DRIVES-IN001 for selection information.
PC Programming Software
Description
DriveTools™ SP Software
See publication 9303-PL002… for
ordering/pricing information.
DriveExplorer™ Software (Lite/Full)
Set-up wizards are available for use with DriveTools SP and DriveExplorer
(Lite/Full) only.
DriveExplorer Lite is available for free download at:
http://www.ab.com/drives/driveexplorer/free_download.html.
Reflected Wave Reduction Modules w/CM Choke
Description
Cat. No.
17A with Common Mode Choke
1204-RWC-17-A
See Appendix A of publication DRIVES-IN001 for selection information.
Communication Option Kits
Description Cat. No.
BACnet
®
MS/TP RS485 Communication Adapter 20-COMM-B
ControlNet™ Communication Adapter (Coax)
20-COMM-C
ControlNet™ Communication Adapter (Coax)
Conformal Coat
20-COMM-C-MX3
DeviceNet™ Communication Adapter
20-COMM-D
DeviceNet™ Communication Adapter Conformal Coat
20-COMM-D-MX3
EtherNet/IP™ Communication Adapter
20-COMM-E
EtherNet/IP™ Communication Adapter Conformal Coat
20-COMM-E-MX3
HVAC Communication Adapter
20-COMM-H
Interbus™ Communication Adapter
20-COMM-I
CANopen
®
Communication Adapter 20-COMM-K
LonWorks
®
Communication Adapter♠
20-COMM-L
Modbus/TCP Communication Adapter
20-COMM-M
PROFIBUS™ DP Communication Adapter
20-COMM-P
ControlNet™ Communication Adapter (Fiber)
20-COMM-Q
Remote I/O Communication Adapter
20-COMM-R
Remote I/O Communication Adapter Conformal Coat
20-COMM-R-MX3
RS485 DF1 Communication Adapter
20-COMM-S
RS485 DF1 Communication Adapter Conformal Coat
20-COMM-S-MX3
External Communications Kit Power Supply
20-XCOMM-AC-
PS1
DPI External Communications Kit
20-XCOMM-DC-
BASE
External DPI I/O Option Board
‡
20-XCOMM-IO-
OPT1
Compact I/O Module (3 Channel)
1769-SM1
Serial Null Modem Adapter
1203-SNM
Smart Self-powered Serial Converter (RS232) includes
1203-SFC and 1202-C10 Cables
1203-SSS
Universal Serial Bus™ (USB) Converter includes 2m
USB, 20-HIM-H10 & 22-HIM-H10 Cables
1203-USB
‡ For use only with DPI External Communications Kits 20-XCOMM-DC-
BASE.
Only Modbus RTU can be used with Vector Control.
♠ Can only be used with Standard Control.
Reflected Wave Reduction Modules
Voltage Drive Cat. No. ND Hp Cat. No.
480V AC
20BD8P0 5.0
1321-RWR8-DP
20BD011 7.5
1321-RWR12-DP
20BD014 10.0
1321-RWR18-DP
20BD022 15.0
1321-RWR25-DP
20BD027 20.0
1321-RWR35-DP
20BD034 25.0
1321-RWR35-DP
20BD040 30.0
1321-RWR45-DP
20BD052 40.0
1321-RWR55-DP
20BD065 50.0
1321-RWR80-DP
20BD077 60.0
1321-RWR80-DP
20BD096 75.0
1321-RWR100-DP
20BD125 100.0
1321-RWR130-DP
20BD156 125.0
1321-RWR160-DP
20BD180 150.0
1321-RWR200-DP
20BD248 200.0
1321-RWR250-DP
20BD292 250.0
1321-RWR320-DP
600V AC
20BE6P1 5.0
1321-RWR8-EP
20BE9P0 7.5
1321-RWR12-EP
20BE011 10.0
1321-RWR12-EP
20BE017 15.0
1321-RWR18-EP
20BE022 20.0
1321-RWR25-EP
20BE027 25.0
1321-RWR35-EP
20BE032 30.0
1321-RWR35-EP
20BE041 40.0
1321-RWR45-EP
20BE052 50.0
1321-RWR55-EP
20BE062 60.0
1321-RWR80-EP
20BE077 75.0
1321-RWR80-EP
20BE099 100.0
1321-RWR100-EP
20BE125 125.0
1321-RWR130-EP
20BE144 150.0
1321-RWR160-EP
