Allen-Bradley PowerFlex 700AFE Product Information

PowerFlex 750-Series Products with TotalFORCE Control 7
Rockwell Automation Publication 750-PC100A-EN-P - December 2016
630 kW 9 1182 Light 20x…C1K1 1300 – 1135 – 2000 – 1500 2000 1500 3500 1500 3000 1500 1362 1400 4
1112 Normal 1223 1667 1067 – 2000 – 1400 1900 1400 3500 1400 3000 1400 1281 1400 4
1040 Heavy 1560 1872 998 – 2000 – 1350 1800 1350 3000 1350 2500 1350 1198 1400 4
710 kW 9 1465 Light 20x…C1K2 1612 – 1406 – 2000 – 1900 2500 1900 4000 1900 3500 1800 1688 1400 4
1175 Normal 1293 1763 1128 – 2000 – 1500 2000 1500 3500 1500 3000 1500 1354 1400 4
1090 Heavy 1635 1962 1046 – 2000 – 1400 1900 1400 3000 1400 3000 1400 1256 1400 4
800 kW 9 1581 Light 20x…C1K4 1739 – 1518 – 2000 – 2000 3000 2000 4500 2000 4000 1900 1821 1400 4
1463 Normal 1612 2198 1406 – 2000 – 1900 2500 1900 4000 1900 3500 1900 1688 1400 4
1175 Heavy 1763 2115 1128 – 2000 – 1500 2000 1500 3500 1500 3000 1500 1354 1400 4
850 kW 10 1715 Light 20x…C1K6 1887 – 1646 – 2000 1250 2400 3000 2400 5000 2400 4500 2400 1976 1400 6
1590 Normal 1749 2385 1526 – 2000 1250 2000 3000 2000 4500 2000 4000 2000 1832 1400 6 1465 Heavy 2198 2637 1406 – 2000 1250 1900 2500 1900 4000 1900 3500 1900 1688 1400 6
1000 kW 10 2150 Light 20x…C1K7 2365 – 2064 – 2000 1250 3000 3800 3000 6000 3000 5000 3000 2477 1400 6
1715 Normal 1887 2573 1646 – 2000 1250 2400 3000 2400 5000 2400 4500 2400 1976 1400 6 1480 Heavy 2220 2664 1421 – 2000 1250 1900 2500 1900 4500 1900 3800 1900 1705 1400 6
1250 kW 10 2330 Light 20x…C2K1 2563 – 2236 – 2000 1250 3000 4000 3000 6000 3000 6000 3000 2684 1400 6
2156 Normal 2372 3234 2069 – 2000 1250 3000 3800 3000 6000 3000 5000 3000 2484 1400 6 1715 Heavy 2573 3087 1646 – 2000 1250 2400 3000 2400 5000 2400 4500 2400 1976 1400 6
1650 kW 11 3078 Light 20x…C2K8 3386 – 2954 2000 2000 – 4000 5000 4000 6000 4000 6000 3800 3546 1400 8
2849 Normal 3134 4274 2735 2000 2000 – 3800 5000 3800 6000 3800 6000 3800 3282 1400 8
2330 Heavy 3495 4194 2236 2000 2000 – 3000 4000 3000 6000 3000 6000 3000 2684 1400 8
2000 kW 12 3846 Light 20x…C3K5 4231 – 3692 2000 2000 1250 5000 6000 5000 6000 5000 6000 5000 4431 1400 10
3542 Normal 3896 5313 3400 2000 2000 1250 4500 6000 4500 6000 4500 6000 4500 4081 1400 10 3032 Heavy 4548 5458 2910 2000 2000 1250 3800 5000 3800 6000 3800 6000 3800 3493 1400 10
(1) ‘Applied Rating’ refers to the motor that will be connected to the drive. For example, a ‘C460’ drive can be used in Normal Duty mode on a 250 kW motor, in Heavy Duty mode on a 200 kW motor or in Light Duty mode on a 315 kW motor. The drive can be programmed for each mode. Wiring and fuses can be
sized based on the programmed mode. For any given drive catalog number, Normal Duty mode provides higher continuous current but smaller overload current with respect to Heavy Duty mode. See parameter 306 [Duty Rating]. Refer to Specifications for an explanation of Duty Ratings.
(2) These AC line fuses (with blown fuse indicators) are included in the drive to provide drive short circuit protection. AC input protection devices for branch circuit protection based on US NEC are listed in the table. Each LCL filter has one fuse per phase. (3) Minimum protection device size is the lowest rated device that supplies maximum protection without nuisance tripping. (4) Maximum protection device size is the highest rated device that supplies drive protection. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum.
(5) Circuit Breaker - inverse time breaker. For US NEC, minimum size is 125% of motor FLA. Ratings shown are maximum. (6) Recommended Motor circuit protector - Instantaneous trip circuit breaker. The trip setting should be set to the input current of the drive and should be sized for the continuous current of the system. (7) These DC line fuses (with blown fuse indicators) are included in the drive to provide drive short circuit protection.
400 Volt AC and 540 Volt DC Input Protection Devices - Frames 8…12 (continued)
400 Volt AC Input 540 Volt DC Input
Applied Rating
(1)
Frame
Cont. Output Amps
Duty
Catalog Number
Output Overload Amps
Continuous AC Input
AC Input Integral Semiconductor Fuse Size (170M Type)
(2)
AC Input Protection Devices
Input Quantities
DC Input Integral Semiconductor Fuse Kit
(7)
Dual Element Time Delay Fuse
Non-Time Delay Fuse Circuit Breaker
(5)
Motor Circuit Protector
(6)
Continuous DC Input
1 min 3 sec Amps 2xLCL
Amps
2xLCL Amps
1xLCL Amps
1/Phase Min
(3)
Max
(4)
1/Phase Min
(3)
Max
(4)
Min Max Amps Amps Qty.
