480 Volt AC and 650 Volt DC Input Protection Devices - Frames 8…12
480 Volt AC Input 650 Volt DC Input
Applied Rating
(1)
Frame
Cont. Output Amps
Duty
Catalog Number
Output Overload Amps
Continuous AC Input
AC Input Integral Semiconductor Fuse Size (170M Type)
(2)
AC Input Protection Devices
Input Quantities
DC Input Integral Semiconductor Fuse Kit
(7)
Dual Element Time Delay Fuse
Non-Time Delay Fuse Circuit Breaker
(5)
Motor Circuit Protector
(6)
Continuous DC Input
(x = G or J) 1 min 3 sec Amps 2xLCL
Amps
2xLCL Amps
1xLCL Amps
1/Phase Min
(3)
Max
(4)
1/Phase Min
(3)
Max
(4)
Min Max Amps Amps Qty.
250 Hp 8 361 Light 20x…D302 397 – 332 – – 900 500 650 500 1000 500 900 500 399 1400 2
302 Normal 332 453 278 – – 900 400 500 400 900 400 750 400 333 1400 2
248 Heavy 372 446 228 – – 900 350 400 350 750 350 600 350 274 1400 2
300 Hp 8 430 Light 20x…D361 473 – 396 – – 900 600 750 600 1200 600 1000 600 475 1400 2
361 Normal 397 542 332 – – 900 500 650 500 1000 500 900 500 399 1400 2
302 Heavy 453 544 278 – – 900 400 500 400 900 400 750 400 333 1400 2
350 Hp 8 485 Light 20x…D430 534 – 446 – – 900 650 800 650 1500 650 1200 650 535 1400 2
430 Normal 473 645 396 – – 900 600 750 600 1200 600 1000 600 475 1400 2
361 Heavy 542 650 332 – – 900 500 650 500 1000 500 900 500 399 1400 2
400 Hp 8 545 Light 20x…D505 600 – 501 – – 900 700 900 700 1600 700 1350 700 602 1400 2
505 Normal 556 758 465 – – 900 650 800 650 1500 650 1200 650 558 1400 2
430 Heavy 645 774 396 – – 900 600 750 600 1200 600 1000 600 475 1400 2
450 Hp 8 617 Light 20x…D545 679 – 568 – – 1250 800 1000 800 1800 800 1500 800 681 1400 2
545 Normal 600 818 501 – – 1250 700 900 700 1600 700 1350 700 602 1400 2
454 Heavy 681 817 418 – – 1250 600 800 600 1350 600 1100 600 501 1400 2
500 Hp 8 710 Light 20x…D617 781 – 653 – – 1250 900 1200 900 2000 900 1800 900 784 1400 2
617 Normal 679 926 568 – – 1250 800 1000 800 1800 800 1500 800 681 1400 2
485 Heavy 728 873 446 – – 1250 700 800 700 1400 700 1200 700 535 1400 2
600 Hp 8 765 Light 20x…D710 842 – 704 – – 1250 1000 1350 1000 2400 1000 1900 1000 845 1400 2
710 Normal 781 1065 653 – – 1250 900 1200 900 2000 900 1800 900 784 1400 2 545 Heavy 818 981 501 – – 1250 700 900 700 1600 700 1350 700 602 1400 2
650 Hp 8 800 Light 20x…D740 880 – 736 – – 1250 1000 1400 1000 2400 1000 2000 1000 883 1400 2
740 Normal 814 1110 681 – – 1250 1000 1200 1000 2000 1000 1800 1000 817 1400 2 617 Heavy 926 1111 568 – – 1250 800 1000 800 1800 800 1500 800 681 1400 2
700 Hp 9 960 Light 20x…D800 1056 – 883 – 1800 – 1200 1600 1200 3000 1200 2400 1200 1060 1400 4
800 Normal 880 1200 736 – 1800 – 1000 1400 1000 2400 1000 2000 1000 883 1400 4 740 Heavy 1110 1332 681 – 1800 – 1000 1200 1000 2000 1000 1800 1000 817 1400 4
800 Hp 9 1045 Light 20x…D960 1150 – 961 – 1800 – 1350 1800 1350 3000 1350 2500 1350 1154 1400 4
960 Normal 1056 1440 883 – 1800 – 1200 1600 1200 3000 1200 2400 1200 1060 1400 4 800 Heavy 1200 1440 736 – 1800 – 1000 1400 1000 2400 1000 2000 1000 883 1400 4
